MeeGo 1.1 for NexusOne status and how to work(Using microSD and Boot vi fastboot).
Updated on 20101107(kernel build, kickstart file, dialer screenshot, fdisk /dev/mmcblk0)
Part2. Single boot: http://blog.mitsutaka.org/2010/11/meego-11-for-nexusone-status-part2-and.html
As you know, MeeGo could be worked on the NexusOne. It was v1.1 development release that time. Then I tried if MeeGo 1.1 final release could work on it. Of course, It could be work. and We've made it more responsive to running.
1. Linux kernel
zImage is loaded from PC via fastboot command. It uses the Android kernel for MSM.This tree is tagged "android-msm-2.6.29-nexusone". We can use it. android-msm-2.6.32, android-msm-2.6.35 branches could be worked. Here is case of android-msm-2.6.32
$ git clone git://android.git.kernel.org/kernel/msm.git -b android-msm-2.6.32 android-msm-2.6.32
$ cd android-msm-2.6.32
Then We use a mahimahi_defconfig using as the base kernel configuration.
$ cp arch/arm/configs/mahimahi_defconfig .config
And customize it. When it boots via fastboot, we don't need initrd.
-CONFIG_BLK_DEV_INITRD=y
+# CONFIG_BLK_DEV_INITRD is not set
If you want to use wifi. You need to change the firmware path.
-CONFIG_BCM4329_FW_PATH="/system/etc/firmware/fw_bcm4329.bin"
+CONFIG_BCM4329_FW_PATH="/lib/firmware/fw_bcm4329.bin"
Any linux distribution uses X.Org as the X Window System. So we can need the Virtual Terminal.
-# CONFIG_VT is not set
+CONFIG_VT=y
+CONFIG_CONSOLE_TRANSLATIONS=y
+CONFIG_VT_CONSOLE=y
+CONFIG_VT_HW_CONSOLE_BINDING=y
Then, Preparing cross compiler. cross compiler uses prebuilt.git from Android git tree.
$ export PATH=$PATH:/prebuilt/linux-x86/toolchain/arm-eabi-4.4.0/bin
Final is compiling.
$ make oldconfig ARCH=arm CROSS_COMPILE=arm-eabi-
$ make zImage modules ARCH=arm CROSS_COMPILE=arm-eabi-
2. Root Filesystem.
Of course, We use the MeeGo as a root filesystem. I created a kickstart file of NexusOne for using the mic2(Image Creator).
$ vi meego-handset-armv7l-nexusone-1.1.ks
lang en_US.UTF-8
keyboard us
timezone --utc America/Los_Angeles
auth --useshadow --enablemd5
part / --size=1600 --ondisk mmcblk0p --fstype=ext3
rootpw meego
xconfig --startxonboot
desktop --autologinuser=meego --defaultdesktop=DUI --session=/usr/bin/mcompositor
user --name meego --groups audio,video --password meego
repo --name=core --baseurl=http://repo.meego.com/MeeGo/releases/1.1/core/repos/armv7l/packages/ --save --debuginfo --source --gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-meego01
repo --name=handset --baseurl=http://repo.meego.com/MeeGo/releases/1.1/handset/repos/armv7l/packages/ --save --debuginfo --source --gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-meego01
repo --name=non-oss --baseurl=http://repo.meego.com/MeeGo/releases/1.1/non-oss/repos/armv7l/packages/ --save --debuginfo --source --gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-meego01
repo --name=updates-core --baseurl=http://repo.meego.com/MeeGo/updates/1.1/core/repos/armv7l/packages/ --save --debuginfo --source --gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-meego01
repo --name=updates-handset --baseurl=http://repo.meego.com/MeeGo/updates/1.1/handset/repos/armv7l/packages/ --save --debuginfo --source --gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-meego01
repo --name=updates-non-oss --baseurl=http://repo.meego.com/MeeGo/updates/1.1/non-oss/repos/armv7l/packages/ --save --debuginfo --source --gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-meego01
%packages
@MeeGo Core
@MeeGo Base
@Minimal MeeGo X Window System
@MeeGo Compliance
@MeeGo Handset Desktop
@MeeGo Handset Applications
@MeeGo Handset Applications Branding
@X for Handsets
@MeeGo Handset Base Support
# Some development tools
openssh-server
wget
strace
bootchart
gdb
gdb-gdbserver
# Some extra tools/libs
connman-test
xorg-x11-utils-xev
# http://bugs.meego.com/show_bug.cgi?id=5651
-meegotouch-inputmethodbridges
-meegotouch-inputmethodframework
-meegotouch-inputmethodkeyboard
-meegotouch-inputmethodengine
# For nexusone
xorg-x11-drv-fbdev
mesa-dri-swrast-driver
yum
yum-utils
tar
%end
%post
set -x
# Prelink not included because of following bug
# http://bugs.meego.com/show_bug.cgi?id=5217
# make sure there aren't core files lying around
rm -f /core*
# open serial line console for embedded system
echo "s0:235:respawn:/sbin/agetty -L 115200 ttyS2 vt100" >> /etc/inittab
# work around for poor key import UI in PackageKit
rm -f /var/lib/rpm/__db*
rpm --rebuilddb
# Set up sane defaults for mthemedaemon settings
Config_Src=`gconftool-2 --get-default-source`
gconftool-2 --direct --config-source $Config_Src \
-s -t string /meegotouch/theme/target NexusOne
# By default N900 has different value than Aava for showStatusBar
sed -i 's!showStatusBar=false!showStatusBar=true!g' /etc/meegotouch/devices.conf
# Temporary fix to the meego-handset-fixup rpm package
sed -i 's!N900!NexusOne!g' /etc/gconf/gconf.xml.defaults/%gconf-tree.xml
#sed -i 's!\/usr\/sbin\/meego-dm!\/usr\/bin\/xinit \/usr\/bin\/startdui!' /etc/inittab
echo "#x:5:respawn:/usr/bin/xinit /usr/bin/startdui" >>/etc/inittab
cat >>/etc/meegotouch/devices.conf <
[NexusOne]
resolutionX=480
resolutionY=800
ppiX=256
ppiY=256
showStatusBar=false
EOF
cat >/usr/bin/startdui <
#!/bin/sh
/usr/bin/mthemedaemon &
/usr/bin/sysuid -software -remote-theme &
/usr/bin/meego-im-uiserver -software -remote-theme &
/usr/bin/mdecorator -software -remote-theme &
/usr/bin/startphonesim
exec /usr/bin/duihome --desktop -software -remote-theme
EOF
chmod +x /usr/bin/startdui
cat >>/etc/rc.d/rc.sysinit <
# Power Management
echo 245000 >/sys/devices/system/cpu/cpu0/cpufreq/scaling_min_freq
echo 998400 >/sys/devices/system/cpu/cpu0/cpufreq/scaling_max_freq
echo ondemand >/sys/devices/system/cpu/cpu0/cpufreq/scaling_governor
echo 40000 >/sys/devices/system/cpu/cpufreq/ondemand/sampling_rate
# Wakelock debug
echo 7 >/sys/module/wakelock/parameters/debug_mask
echo 1 >/proc/sys/kernel/panic_on_oops
echo 0 >/proc/sys/kernel/hung_task_timeout_secs
echo 4 >/proc/cpu/alignment
echo 10000000 >/proc/sys/kernel/sched_latency_ns
echo 2000000 >/proc/sys/kernel/sched_wakeup_granularity_ns
echo 1 >/proc/sys/kernel/sched_compat_yield
echo 0 >/proc/sys/kernel/sched_child_runs_first
# Write value must be consistent with the above properties.
# Note that the driver only supports 6 slots, so we have HOME_APP at the
# same memory level as services.
echo 0,1,2,7,14,15 >/sys/module/lowmemorykiller/parameters/adj
echo 1 >/proc/sys/vm/overcommit_memory
echo 4 >/proc/sys/vm/min_free_order_shift
echo 1536,2048,4096,5120,5632,6144 >/sys/module/lowmemorykiller/parameters/minfree
# Set init its forked children's oom_adj.
echo -16 >/proc/1/oom_adj
# Tweak background writeout
echo 200 >/proc/sys/vm/dirty_expire_centisecs
echo 5 >/proc/sys/vm/dirty_background_ratio
mkdir -p /mnt/sdcard /mnt/system /mnt/cache /mnt/userdata
(sleep 5; /sbin/adbd) &
EOF
mkdir -p /system/bin
ln -s /bin/bash /system/bin/sh
swprogs="
/usr/share/applications/dialer.desktop
/usr/share/applications/duicontrolpanel.desktop
/usr/share/applications/meego-handset-calendar.desktop
/usr/share/applications/meego-handset-chat.desktop
/usr/share/applications/meego-handset-people.desktop
/usr/share/applications/meego-handset-video.desktop
/usr/share/applications/meegomusic.desktop
/usr/share/applications/meegophotos.desktop
/usr/share/applications/settings.desktop
/usr/share/applications/sms.desktop
/etc/xdg/autostart/applauncherd.desktop
/etc/xdg/autostart/mdecorator.desktop
/etc/xdg/autostart/meego-im-uiserver.desktop
/etc/xdg/autostart/meegotouch-systemui.desktop
"
for prog in $swprogs; do
sed -e "s/Exec=.*$/\0 -software/" -i $prog
done
sed 's!session=\/usr\/bin\/mcompositor!session=\/usr\/bin\/duihome -software \&!' -i /etc/sysconfig/uxlaunch
# Normal bootchart is only 30 long so we use this to get longer bootchart during startup when needed.
cat > /sbin/bootchartd-long << EOF
#!/bin/sh
exec /sbin/bootchartd -n 4000
EOF
chmod +x /sbin/bootchartd-long
# Temporary fix for BMC#8664 to get fennec startup time more reasonable.
mkdir -p /home/meego/.mozilla/
chown -R meego:meego /home/meego/.mozilla/
cat >>/etc/fstab << EOF
tmpfs /home/meego/.mozilla tmpfs size=20m 0 0
/dev/mmcblk0p1 /mnt/sdcard vfat defaults 0 0
/dev/mtdblock3 /mnt/system yaffs2 defaults 0 0
/dev/mtdblock4 /mnt/cache yaffs2 defaults 0 0
/dev/mtdblock5 /mnt/userdata yaffs2 defaults 0 0
EOF
%end
%post --nochroot
set -x
if [ -n "$IMG_NAME" ]; then
echo "BUILD: $IMG_NAME" >> $INSTALL_ROOT/etc/meego-release
fi
# Creating rootfs tar ball.
for dir in `mount | grep $INSTALL_ROOT\/ | awk '{ print $3 }' | sort -r`; do
umount $dir
done
outdir=`pwd`
(cd $INSTALL_ROOT; tar czvf $outdir/${IMG_NAME}-rootfs.tar.gz .)
%end
Rootfs tar ball is smarter then raw image or filesystem image. I used it. and It extract to you microSD card. Layout the microSD partition. /dev/mmcblk0p1 is used from Android. /dev/mmcblk0p2 is MeeGo rootfs.
# fdisk -l
Disk /dev/mmcblk0: 4013 MB, 4013948928 bytes
124 heads, 62 sectors/track, 1019 cylinders
Units = cylinders of 7688 * 512 = 3936256 bytes
Disk identifier: 0x00029d6c
Device Boot Start End Blocks Id System
/dev/mmcblk0p1 1 131 503533 c W95 FAT32 (LBA)
/dev/mmcblk0p2 132 959 3182832 83 Linux
3. Boot
The microSD card insert to NexusOne. And Boot up fastboot mode. Then run the following command. root= is MeeGo root filesystem.
$ fastboot -c 'init=/sbin/init rootwait root=/dev/mmcblk0p2 rootfstype=ext3 rw' boot zImage
creating boot image...
creating boot image - 2240512 bytes
downloading 'boot.img'... OKAY
booting... OKAY
Enjoy!
They are some messages.
dmesg
[ 0.000000] Initializing cgroup subsys cpu
[ 0.000000] Linux version 2.6.29-01118-ga971bfd (mitsutaka@localhost) (gcc version 4.4.0 (GCC) ) #21 PREEMPT Sun Oct 31 10:08:45 JST 2010
[ 0.000000] CPU: ARMv7 Processor [510f00f2] revision 2 (ARMv7), cr=10c5387f
[ 0.000000] CPU: VIPT nonaliasing data cache, VIVT ASID tagged instruction cache
[ 0.000000] Machine: mahimahi
[ 0.000000] Ignoring unrecognised tag 0x4d534d71
[ 0.000000] Ignoring unrecognised tag 0x4d534d72
[ 0.000000] Ignoring unrecognised tag 0x4d534d73
[ 0.000000] Ignoring unrecognised tag 0x4d534d74
[ 0.000000] Ignoring unrecognised tag 0x4d534d75
[ 0.000000] Ignoring unrecognised tag 0x4d534d76
[ 0.000000] Ignoring unrecognised tag 0x5441000a
[ 0.000000] Ignoring unrecognised tag 0x41387898
[ 0.000000] Memory policy: ECC disabled, Data cache writeback
[ 0.000000] On node 0 totalpages: 56064
[ 0.000000] free_area_init_node: node 0, pgdat c03e12e8, node_mem_map c0490000
[ 0.000000] Normal zone: 438 pages used for memmap
[ 0.000000] Normal zone: 0 pages reserved
[ 0.000000] Normal zone: 55626 pages, LIFO batch:15
[ 0.000000] Built 1 zonelists in Zone order, mobility grouping on. Total pages: 55626
[ 0.000000] Kernel command line: board_mahimahi.disable_uart3=0 board_mahimahi.usb_h2w_sw=0 board_mahimahi.disable_sdcard=0 diag.enabled=0 board_mahimahi.debug_uart=0 smisize=0 androidboot.baseband=4.06.00.12_7 androidboot.cid=GOOGL001 androidboot.carrier=GOOGLE androidboot.mid=PB9910000 androidboot.keycaps=qwerty androidboot.mode=normal androidboot.serialno=HT015P803993 androidboot.bootloader=0.33.0012 init=/sbin/init rootwait root=/dev/mmcblk0p2 rootfstype=ext3 rw
[ 0.000000] Unknown boot option `board_mahimahi.disable_uart3=0': ignoring
[ 0.000000] Unknown boot option `board_mahimahi.usb_h2w_sw=0': ignoring
[ 0.000000] Unknown boot option `androidboot.baseband=4.06.00.12_7': ignoring
[ 0.000000] Unknown boot option `androidboot.cid=GOOGL001': ignoring
[ 0.000000] Unknown boot option `androidboot.carrier=GOOGLE': ignoring
[ 0.000000] Unknown boot option `androidboot.mid=PB9910000': ignoring
[ 0.000000] Unknown boot option `androidboot.keycaps=qwerty': ignoring
[ 0.000000] Unknown boot option `androidboot.mode=normal': ignoring
[ 0.000000] Unknown boot option `androidboot.bootloader=0.33.0012': ignoring
[ 0.000000] PID hash table entries: 1024 (order: 10, 4096 bytes)
[ 0.000000] Console: colour dummy device 80x30
[ 0.000000] console [tty0] enabled
[ 0.000610] Dentry cache hash table entries: 32768 (order: 5, 131072 bytes)
[ 0.000946] Inode-cache hash table entries: 16384 (order: 4, 65536 bytes)
[ 0.012634] Memory: 219MB = 219MB total
[ 0.012695] Memory: 217344KB available (3656K code, 870K data, 100K init)
[ 0.013275] Calibrating delay loop... 509.54 BogoMIPS (lpj=2547712)
[ 0.239929] Mount-cache hash table entries: 512
[ 0.240844] Initializing cgroup subsys debug
[ 0.240875] Initializing cgroup subsys cpuacct
[ 0.240905] Initializing cgroup subsys freezer
[ 0.240936] CPU: Testing write buffer coherency: ok
[ 0.243591] net_namespace: 780 bytes
[ 0.244140] regulator: core version 0.5
[ 0.244445] NET: Registered protocol family 16
[ 0.245635] mahimahi_init() revision=129
[ 3.801177] mahimahi_init_mmc()+
[ 3.801544] mahimahi_init_mmc()-
[ 3.809417] bio: create slab at 0
[ 3.810760] msm_i2c_probe
[ 3.810974] msm_i2c_probe: clk_ctl 35d, 100000 Hz
[ 3.812377] regulator: VDCDC1: 1000 <--> 1300 mV
[ 3.812591] regulator: VDCDC2: 1260 mV
[ 3.812774] regulator: VDCDC3: 800 <--> 3300 mV
[ 3.813018] regulator: LDO1: 1000 <--> 3150 mV
[ 3.813201] regulator: LDO2: 3300 mV
[ 3.815246] Bluetooth: Core ver 2.15
[ 3.815521] NET: Registered protocol family 31
[ 3.815551] Bluetooth: HCI device and connection manager initialized
[ 3.815582] Bluetooth: HCI socket layer initialized
[ 3.817169] NET: Registered protocol family 2
[ 3.817382] IP route cache hash table entries: 2048 (order: 1, 8192 bytes)
[ 3.817962] TCP established hash table entries: 8192 (order: 4, 65536 bytes)
[ 3.818176] TCP bind hash table entries: 8192 (order: 3, 32768 bytes)
[ 3.818267] TCP: Hash tables configured (established 8192 bind 8192)
[ 3.818298] TCP reno registered
[ 3.818634] NET: Registered protocol family 1
[ 3.819610] smd_init()
[ 3.819641] smd_core_init()
[ 3.819732] smd_core_init() done
[ 3.819763] msm_init_last_radio_log: last radio log is 40000 bytes long
[ 3.820281] smd_alloc_channel() cid=00 size=08192 'SMD_DS'
[ 3.820495] smd_alloc_channel() cid=01 size=08192 'SMD_DIAG'
[ 3.820678] smd_alloc_channel() cid=02 size=08192 'SMD_RPCCALL'
[ 3.820831] smd_alloc_channel() cid=07 size=32768 'SMD_DATA1'
[ 3.821044] smd_alloc_channel() cid=08 size=08192 'SMD_DATA2'
[ 3.821197] smd_alloc_channel() cid=09 size=08192 'SMD_DATA3'
[ 3.821411] smd_alloc_channel() cid=11 size=32768 'SMD_DATA5'
[ 3.821563] smd_alloc_channel() cid=12 size=32768 'SMD_DATA6'
[ 3.821746] smd_alloc_channel() cid=13 size=32768 'SMD_DATA7'
[ 3.821899] smd_alloc_channel() cid=15 size=08192 'SMD_DATA9'
[ 3.822082] smd_alloc_channel() cid=27 size=08192 'SMD_GPSNMEA'
[ 3.822265] smd_alloc_channel() cid=40 size=08192 'DSP_DIAG'
[ 3.822448] smd_alloc_channel() cid 41 does not exist
[ 3.822509] smd_alloc_channel() cid=42 size=08192 'DSP_DAL_AQ_VID'
[ 3.822662] smd_alloc_channel() cid=43 size=08192 'DSP_DAL_AQ_AUD'
[ 3.822845] smd_alloc_channel() cid=46 size=08192 'DSP_DAL00'
[ 3.822998] smd_alloc_channel() cid 47 does not exist
[ 3.823028] smd_alloc_channel() cid=48 size=08192 'SMD_DAL_AM_AUD'
[ 3.823211] smd_alloc_channel() cid=49 size=08192 'SMD_DAL00'
[ 3.823394] smd_alloc_channel() cid=50 size=08192 'SMD_DATA5_CNTL'
[ 3.823547] smd_alloc_channel() cid=51 size=08192 'SMD_DATA6_CNTL'
[ 3.823760] smd_alloc_channel() cid=52 size=08192 'SMD_DATA7_CNTL'
[ 3.825073] SMD: ch 2 1 -> 2
[ 3.825225] Switched to high resolution mode on CPU 0
[ 3.827972] mdp_probe: initialized
[ 3.828033] spi: SPI_CONFIG=8f
[ 3.828063] spi: SPI_IO_CONTROL=401
[ 3.828094] spi: SPI_OPERATIONAL=85
[ 3.828125] spi: SPI_ERROR_FLAGS_EN=7f
[ 3.828125] spi: SPI_ERROR_FLAGS=7f
[ 3.828155] -mahimahi_init_spi_hack()
[ 3.828552] Registered led device: lcd-backlight
[ 3.831054] mahimahi-microp 0-0066: microp version [0B][15]
[ 3.831542] input: lightsensor-level as /devices/virtual/input/input0
[ 3.831939] Registered led device: green
[ 3.832183] Registered led device: amber
[ 3.832366] Registered led device: red
[ 3.832580] Registered led device: blue
[ 3.832794] Registered led device: jogball-backlight
[ 3.832977] Registered led device: button-backlight
[ 3.833496] microp_function_initialize: als_kadc=0x4f, als_gadc=0xc0
[ 3.848602] flashlight_init
[ 3.848663] flashlight_probe
[ 3.848663] flashlight_setup_gpio
[ 3.848907] Registered led device: flashlight
[ 3.849609] smd_alloc_channel() cid 41 does not exist
[ 3.849639] smd_alloc_channel() cid 47 does not exist
[ 3.851470] H2W: htc_35mm_jack driver register
[ 3.852172] input: h2w headset as /devices/virtual/input/input1
[ 3.861419] ashmem: initialized
[ 3.862426] yaffs Oct 30 2010 22:16:35 Installing.
[ 3.866638] alg: No test for stdrng (krng)
[ 3.866760] io scheduler noop registered
[ 3.866790] io scheduler anticipatory registered (default)
[ 3.867462] +mddi_client_nt35399_init()
[ 3.867950] samsung_oled_panel_init: +()
[ 3.868255] samsung_oled_panel_init: -()
[ 3.868957] msmfb_probe() installing 480 x 800 panel
[ 3.869445] mdp_lcdc_probe: initialized
[ 3.882446] msm_serial: driver initialized
[ 3.882781] msm_serial_hs.0: ttyHS0 at MMIO 0xa0200000 (irq = 44) is a MSM HS UART
[ 3.883270] msm_serial_hs module loaded
[ 3.887481] loop: module loaded
[ 3.887603] pmem: 1 init
[ 3.888610] pmem_adsp: 1 init
[ 3.890472] pmem_camera: 1 init
[ 3.891296] Android kernel panic handler initialized (bind=crashdata)
[ 3.891357] PPP generic driver version 2.4.2
[ 3.891723] PPP Deflate Compression module registered
[ 3.891754] PPP BSD Compression module registered
[ 3.892639] PPP MPPE Compression module registered
[ 3.892669] NET: Registered protocol family 24
[ 3.893646] rmnet0 (): not using net_device_ops yet
[ 3.894287] rmnet1 (): not using net_device_ops yet
[ 3.894897] rmnet2 (): not using net_device_ops yet
[ 3.895538] Linux video capture interface: v2.00
[ 3.895690] msm_v4l2: msm_v4l2_init
[ 3.896179] s5k3e2fx_sensor_probe
[ 4.508972] allocated dma buffer at ffa01000, dma_addr 2d55e000
[ 4.509094] read CFG0 = aa5400c0, CFG1 = 6746a
[ 4.509124] CFG0 = e85408c0, CFG1 = 4745e
[ 4.509155] CFG0: cw/page=3 ud_sz=516 ecc_sz=10 spare_sz=0 num_addr_cycles=5
[ 4.509246] NAND_READ_ID = 5510bcad
[ 4.509399] status: e03120
[ 4.509429] nandid: 5510bcad maker ad device bc
[ 4.509490] CFG0: cw/page=3 ud_sz=512 ecc_sz=10 spare_sz=4
[ 4.509582] DEV_CMD1: f00f3000
[ 4.509643] <6>NAND_EBI2_ECC_BUF_CFG: 1ff
[ 4.509674] flash_id: 5510bcad size 20000000
[ 4.509704] Creating 6 MTD partitions on "msm_nand":
[ 4.509735] 0x000003ee0000-0x000003fc0000 : "misc"
[ 4.511718] 0x000004240000-0x000004740000 : "recovery"
[ 4.517822] 0x000004740000-0x0000049c0000 : "boot"
[ 4.521270] 0x0000049c0000-0x00000dac0000 : "system"
[ 4.674621] 0x00000dac0000-0x0000139c0000 : "cache"
[ 4.775482] 0x0000139c0000-0x00001fe00000 : "userdata"
[ 4.983428] usb_probe() io=ce060000, irq=58, dma=ffa02000(2d562000)
[ 4.984161] usb_function_register() 'adb'
[ 4.984375] usb_function_register() 'usb_mass_storage'
[ 4.984527] usb_function_register() 'diag'
[ 4.984558] msm_hsusb: functions bound. starting.
[ 4.984588] usb_bind_func() 'usb_mass_storage'
[ 4.985290] usb_mass_storage usb_mass_storage: Number of LUNs=1
[ 4.985382] usb_bind_func() 'adb'
[ 4.985382] adb_bind() cd55a878, cd55aa38
[ 4.985748] adb_bind() allocated 4 tx requests
[ 4.986267] usb_bind_func() 'diag'
[ 4.986755] SMD: ch 1 1 -> 2
[ 4.987426] hsusb: IDLE -> ONLINE
[ 4.987579] hsusb: reset controller
[ 4.987854] mahimahi_ts_power: power 1
[ 5.025329] msm_hsusb_phy_reset: success
[ 5.135864] msm_i2c msm_i2c.0: error, status 43c8
[ 5.135894] msm_i2c msm_i2c.0: Error during data xfer (-5)
[ 5.175323] ulpi: write 0x0c to 0x31
[ 5.175323] ulpi: write 0x31 to 0x32
[ 5.175354] ulpi: write 0x1d to 0x0d
[ 5.175384] ulpi: write 0x1d to 0x10
[ 5.175415] ept #0 out max:64 head:ffa02000 bit:0
[ 5.175415] ept #1 out max:512 head:ffa02080 bit:1
[ 5.175445] ept #2 out max:512 head:ffa02100 bit:2
[ 5.175476] ept #3 out max:512 head:ffa02180 bit:3
[ 5.175506] ept #0 in max:64 head:ffa02040 bit:16
[ 5.175537] ept #1 in max:512 head:ffa020c0 bit:17
[ 5.175567] ept #2 in max:512 head:ffa02140 bit:18
[ 5.175567] ept #3 in max:512 head:ffa021c0 bit:19
[ 5.175628] usb: notify offline
[ 5.175659] diag_configure() 0
[ 5.175659] msm_hsusb: enable pullup
[ 5.175689] hsusb: ONLINE -> OFFLINE
[ 5.175720] ### notify_usb_connected(0) ###
[ 5.175750] diag_configure() 0
[ 5.175750] msm_hsusb: disable pullup
[ 5.215332] msm_hsusb_phy_reset: success
[ 5.246032] synaptics_ts_probe: Product Major Version 1
[ 5.246704] synaptics_ts_probe: Product Minor Version 3
[ 5.247406] synaptics_ts_probe: product property 2
[ 5.248077] synaptics_ts_probe: device control 81
[ 5.248748] synaptics_ts_probe: interrupt enable 1
[ 5.250640] synaptics_ts_probe: 0xe0: 1 1 1 2 1 3 0 0
[ 5.251678] synaptics_ts_probe: Sensor properties 701
[ 5.254852] synaptics_ts_probe: max_x 4050, max_y 6822
[ 5.254882] synaptics_ts_probe: inactive_x -210 -168, inactive_y -127 -341
[ 5.254913] synaptics_ts_probe: snap_x 0-0 0-0, snap_y 0-0 0-0
[ 5.255310] input: synaptics-rmi-touchscreen as /devices/virtual/input/input2
[ 5.256072] synaptics_ts_probe: Start touchscreen synaptics-rmi-touchscreen in interrupt mode
[ 5.256927] GPIO Matrix Keypad Driver: Start keypad matrix for mahimahi-keypad... in interrupt mode
[ 5.257080] GPIO Input Driver: Start gpio inputs for mahimahi-keypad... in interrupt mode
[ 5.257751] input: mahimahi-keypad as /devices/virtual/input/input3
[ 5.258392] input: mahimahi-nav as /devices/virtual/input/input4
[ 5.258819] capella_cm3602_probe: probe
[ 5.258850] capella_cm3602_probe: allocating input device
[ 5.258911] capella_cm3602_probe: registering input device
[ 5.259277] input: proximity as /devices/virtual/input/input5
[ 5.259521] capella_cm3602_probe: registering misc device
[ 5.259735] capella_cm3602_setup
[ 5.259796] proximity 1
[ 5.260314] using input dev h2w headset for key reset
[ 5.260375] using input dev mahimahi-keypad for key reset
[ 5.260437] using input dev mahimahi-nav for key reset
[ 5.261505] using rtc device, msm_rtc, for alarms<6>rs30000048:00010000 rs30000048:00010000: rtc core: registered msm_rtc as rtc0
[ 5.261688] AKM8973 compass driver: init
[ 5.263183] input: compass as /devices/virtual/input/input6
[ 5.263946] a1026_init
[ 5.264373] Driver for 1-wire Dallas network protocol.
[ 5.265777] msm_i2c msm_i2c.0: error, status 43c8
[ 5.265838] msm_i2c msm_i2c.0: Error during data xfer (-5)
[ 5.265899] ds2482 0-0018: i2c write c3 87 failed, -5, retries left 5
[ 5.266265] msm_i2c msm_i2c.0: error, status 43c8
[ 5.266296] msm_i2c msm_i2c.0: Error during data xfer (-5)
[ 5.266357] ds2482 0-0018: i2c write c3 87 failed, -5, retries left 4
[ 5.266723] msm_i2c msm_i2c.0: error, status 43c8
[ 5.266754] msm_i2c msm_i2c.0: Error during data xfer (-5)
[ 5.266815] ds2482 0-0018: i2c write c3 87 failed, -5, retries left 3
[ 5.267150] msm_i2c msm_i2c.0: error, status 43c8
[ 5.267211] msm_i2c msm_i2c.0: Error during data xfer (-5)
[ 5.267242] ds2482 0-0018: i2c write c3 87 failed, -5, retries left 2
[ 5.267608] msm_i2c msm_i2c.0: error, status 43c8
[ 5.267669] msm_i2c msm_i2c.0: Error during data xfer (-5)
[ 5.267700] ds2482 0-0018: i2c write c3 87 failed, -5, retries left 1
[ 5.268066] msm_i2c msm_i2c.0: error, status 43c8
[ 5.268096] msm_i2c msm_i2c.0: Error during data xfer (-5)
[ 5.268157] ds2482 0-0018: i2c write c3 87 failed, -5, retries left 0
[ 5.269653] device-mapper: uevent: version 1.0.3
[ 5.270202] device-mapper: ioctl: 4.14.0-ioctl (2008-04-23) initialised: [email protected]
[ 5.270294] Bluetooth: HCI UART driver ver 2.2
[ 5.270324] Bluetooth: HCI H4 protocol initialized
[ 5.270355] Bluetooth: HCILL protocol initialized
[ 5.271697] mmc0: Qualcomm MSM SDCC at 0x00000000a0300000 irq 24,0 dma 8
[ 5.271759] mmc0: 4 bit data mode enabled
[ 5.271759] mmc0: MMC clock 144000 -> 50000000 Hz, PCLK 64000000 Hz
[ 5.271789] mmc0: Slot eject status = 1
[ 5.271820] mmc0: Power save feature enable = 1
[ 5.271850] mmc0: DM non-cached buffer at ffa04000, dma_addr 0x2d58e000
[ 5.271881] mmc0: DM cmd busaddr 0x2d58e000, cmdptr busaddr 0x2d58e300
[ 5.272796] mmc1: Qualcomm MSM SDCC at 0x00000000a0400000 irq 26,0 dma 8
[ 5.272827] mmc1: 4 bit data mode enabled
[ 5.272857] mmc1: MMC clock 144000 -> 50000000 Hz, PCLK 64000000 Hz
[ 5.272888] mmc1: Slot eject status = 0
[ 5.272918] mmc1: Power save feature enable = 1
[ 5.272918] mmc1: DM non-cached buffer at ffa05000, dma_addr 0x2d590000
[ 5.272949] mmc1: DM cmd busaddr 0x2d590000, cmdptr busaddr 0x2d590300
[ 5.274658] logger: created 64K log 'log_main'
[ 5.274902] logger: created 256K log 'log_events'
[ 5.275115] logger: created 64K log 'log_radio'
[ 5.275207] ram_console: got buffer at 3a00000, size 40000
[ 5.275390] ram_console: found existing buffer, size 28431, start 28431
[ 5.401641] console [ram-1] enabled
[ 5.455413] TCP cubic registered
[ 5.455993] NET: Registered protocol family 10
[ 5.457031] lo: Disabled Privacy Extensions
[ 5.458343] Mobile IPv6
[ 5.458618] IPv6 over IPv4 tunneling driver
[ 5.459625] sit0: Disabled Privacy Extensions
[ 5.460632] ip6tnl0: Disabled Privacy Extensions
[ 5.461059] NET: Registered protocol family 17
[ 5.461242] NET: Registered protocol family 15
[ 5.461547] Bluetooth: L2CAP ver 2.13
[ 5.461700] Bluetooth: L2CAP socket layer initialized
[ 5.461853] Bluetooth: SCO (Voice Link) ver 0.6
[ 5.462127] Bluetooth: SCO socket layer initialized
[ 5.463043] Bluetooth: RFCOMM socket layer initialized
[ 5.463439] Bluetooth: RFCOMM TTY layer initialized
[ 5.463592] Bluetooth: RFCOMM ver 1.11
[ 5.463745] Bluetooth: BNEP (Ethernet Emulation) ver 1.3
[ 5.464019] Bluetooth: HIDP (Human Interface Emulation) ver 1.2
[ 5.464355] ThumbEE CPU extension supported.
[ 5.465087] clock_late_init() disabled 18 unused clocks
[ 5.465423] mahimahi_wifi_init: start
[ 5.475402] VFP support v0.3: implementor 51 architecture 0 part 0f variant 0 rev 1
[ 5.480468] rs30000048:00010000 rs30000048:00010000: setting system clock to 2010-10-30 01:32:33 UTC (1288402353)
[ 5.480957] Waiting for root device /dev/mmcblk0p2...
[ 5.520751] mmc1: Command timeout
[ 5.526733] mmc1: Command timeout
[ 5.532745] mmc1: Command timeout
[ 5.538726] mmc1: Command timeout
[ 5.930267] batt: 100%, 4157 mV, 70 mA (5 avg), 30.0 C, 1361 mAh
[ 5.930633] batt: charging OFF [FULL]
[ 6.422637] mmc1: host does not support reading read-only switch. assuming write-enable.
[ 6.422851] mmc1: new high speed SDHC card at address 0007
[ 6.423675] mmcblk0: mmc1:0007 SD04G 3.73 GiB
[ 6.424133] mmcblk0: p1 p2 p3
[ 9.362518] cable_status_update: status=1
[ 9.385375] hsusb: OFFLINE -> ONLINE
[ 9.385650] hsusb: reset controller
[ 9.425354] msm_hsusb_phy_reset: success
[ 9.575347] ulpi: write 0x0c to 0x31
[ 9.575500] ulpi: write 0x31 to 0x32
[ 9.575653] ulpi: write 0x1d to 0x0d
[ 9.575897] ulpi: write 0x1d to 0x10
[ 9.576049] ept #0 out max:64 head:ffa02000 bit:0
[ 9.576202] ept #1 out max:512 head:ffa02080 bit:1
[ 9.576477] ept #2 out max:512 head:ffa02100 bit:2
[ 9.576629] ept #3 out max:512 head:ffa02180 bit:3
[ 9.576904] ept #0 in max:64 head:ffa02040 bit:16
[ 9.577056] ept #1 in max:512 head:ffa020c0 bit:17
[ 9.577331] ept #2 in max:512 head:ffa02140 bit:18
[ 9.577484] ept #3 in max:512 head:ffa021c0 bit:19
[ 9.577636] usb: notify offline
[ 9.577911] diag_configure() 0
[ 9.578063] msm_hsusb: enable pullup
[ 9.581359] usb: suspend
[ 9.715301] usb: reset
[ 9.717590] usb: portchange USB_SPEED_HIGH
[ 10.191284] usb: reset
[ 10.193542] usb: portchange USB_SPEED_HIGH
[ 10.366394] diag_configure() 1
[ 10.366546] ### notify_usb_connected(1) ###
[ 10.366790] usb_mass_storage usb_mass_storage: config #1
[ 11.330566] EXT3-fs warning: mounting fs with errors, running e2fsck is recommended
[ 11.330810] kjournald starting. Commit interval 5 seconds
[ 11.539764] EXT3 FS on mmcblk0p2, internal journal
[ 11.540039] EXT3-fs: recovery complete.
[ 11.750671] EXT3-fs: mounted filesystem with ordered data mode.
[ 11.750946] VFS: Mounted root (ext3 filesystem) on device 179:2.
[ 11.751434] Freeing init memory: 100K
[ 13.549499] udev: starting version 161
[ 13.959869] wifi_set_power = 1
[ 13.959869] mahimahi_wifi_power: 1
[ 14.318908] wifi_set_carddetect = 1
[ 14.318939] mahimahi_wifi_set_carddetect: 1
[ 14.318939] mmc0: card_present 1
[ 14.318939] mmc0: Slot status change detected (0 -> 1)
[ 14.322021]
[ 14.322021] Dongle Host Driver, version 4.218.161.0
[ 15.062774] msm_nand_read_oob: unsupported ops->len, 512
[ 15.062805] end_request: I/O error, dev mtdblock0, sector 0
[ 15.062835] Buffer I/O error on device mtdblock0, logical block 0
[ 15.062896] msm_nand_read_oob: unsupported ops->len, 512
[ 15.062896] end_request: I/O error, dev mtdblock0, sector 8
[ 15.062927] Buffer I/O error on device mtdblock0, logical block 1
[ 15.062927] msm_nand_read_oob: unsupported ops->len, 512
[ 15.062957] end_request: I/O error, dev mtdblock0, sector 16
[ 15.062957] Buffer I/O error on device mtdblock0, logical block 2
[ 15.062988] msm_nand_read_oob: unsupported ops->len, 512
[ 15.062988] end_request: I/O error, dev mtdblock0, sector 24
[ 15.063018] Buffer I/O error on device mtdblock0, logical block 3
[ 15.063018] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063049] end_request: I/O error, dev mtdblock0, sector 32
[ 15.063049] Buffer I/O error on device mtdblock0, logical block 4
[ 15.063079] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063079] end_request: I/O error, dev mtdblock0, sector 40
[ 15.063110] Buffer I/O error on device mtdblock0, logical block 5
[ 15.063110] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063140] end_request: I/O error, dev mtdblock0, sector 48
[ 15.063140] Buffer I/O error on device mtdblock0, logical block 6
[ 15.063171] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063171] end_request: I/O error, dev mtdblock0, sector 56
[ 15.063201] Buffer I/O error on device mtdblock0, logical block 7
[ 15.063201] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063232] end_request: I/O error, dev mtdblock0, sector 64
[ 15.063232] Buffer I/O error on device mtdblock0, logical block 8
[ 15.063262] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063262] end_request: I/O error, dev mtdblock0, sector 72
[ 15.063262] Buffer I/O error on device mtdblock0, logical block 9
[ 15.063293] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063293] end_request: I/O error, dev mtdblock0, sector 80
[ 15.063323] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063323] end_request: I/O error, dev mtdblock0, sector 88
[ 15.063354] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063354] end_request: I/O error, dev mtdblock0, sector 96
[ 15.063385] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063385] end_request: I/O error, dev mtdblock0, sector 104
[ 15.063415] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063415] end_request: I/O error, dev mtdblock0, sector 112
[ 15.063446] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063446] end_request: I/O error, dev mtdblock0, sector 120
[ 15.063476] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063476] end_request: I/O error, dev mtdblock0, sector 128
[ 15.063507] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063507] end_request: I/O error, dev mtdblock0, sector 136
[ 15.063537] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063537] end_request: I/O error, dev mtdblock0, sector 144
[ 15.063568] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063568] end_request: I/O error, dev mtdblock0, sector 152
[ 15.063598] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063598] end_request: I/O error, dev mtdblock0, sector 160
[ 15.063629] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063629] end_request: I/O error, dev mtdblock0, sector 168
[ 15.063659] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063659] end_request: I/O error, dev mtdblock0, sector 176
[ 15.063690] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063690] end_request: I/O error, dev mtdblock0, sector 184
[ 15.063720] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063720] end_request: I/O error, dev mtdblock0, sector 192
[ 15.063751] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063751] end_request: I/O error, dev mtdblock0, sector 200
[ 15.063781] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063781] end_request: I/O error, dev mtdblock0, sector 208
[ 15.063812] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063812] end_request: I/O error, dev mtdblock0, sector 216
[ 15.063842] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063842] end_request: I/O error, dev mtdblock0, sector 224
[ 15.063873] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063873] end_request: I/O error, dev mtdblock0, sector 232
[ 15.063903] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063903] end_request: I/O error, dev mtdblock0, sector 240
[ 15.063934] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063964] end_request: I/O error, dev mtdblock0, sector 248
[ 15.063964] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063995] end_request: I/O error, dev mtdblock0, sector 0
[ 15.070983] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071014] end_request: I/O error, dev mtdblock1, sector 0
[ 15.071075] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071105] end_request: I/O error, dev mtdblock1, sector 8
[ 15.071105] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071136] end_request: I/O error, dev mtdblock1, sector 16
[ 15.071136] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071166] end_request: I/O error, dev mtdblock1, sector 24
[ 15.071166] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071197] end_request: I/O error, dev mtdblock1, sector 32
[ 15.071197] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071228] end_request: I/O error, dev mtdblock1, sector 40
[ 15.071228] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071258] end_request: I/O error, dev mtdblock1, sector 48
[ 15.071258] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071289] end_request: I/O error, dev mtdblock1, sector 56
[ 15.071289] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071319] end_request: I/O error, dev mtdblock1, sector 64
[ 15.071319] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071350] end_request: I/O error, dev mtdblock1, sector 72
[ 15.071350] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071380] end_request: I/O error, dev mtdblock1, sector 80
[ 15.071380] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071411] end_request: I/O error, dev mtdblock1, sector 88
[ 15.071411] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071441] end_request: I/O error, dev mtdblock1, sector 96
[ 15.071441] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071472] end_request: I/O error, dev mtdblock1, sector 104
[ 15.071472] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071502] end_request: I/O error, dev mtdblock1, sector 112
[ 15.071502] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071533] end_request: I/O error, dev mtdblock1, sector 120
[ 15.071533] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071563] end_request: I/O error, dev mtdblock1, sector 128
[ 15.071563] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071594] end_request: I/O error, dev mtdblock1, sector 136
[ 15.071594] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071624] end_request: I/O error, dev mtdblock1, sector 144
[ 15.071624] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071655] end_request: I/O error, dev mtdblock1, sector 152
[ 15.071655] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071685] end_request: I/O error, dev mtdblock1, sector 160
[ 15.071685] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071716] end_request: I/O error, dev mtdblock1, sector 168
[ 15.071716] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071746] end_request: I/O error, dev mtdblock1, sector 176
[ 15.071746] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071777] end_request: I/O error, dev mtdblock1, sector 184
[ 15.071777] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071807] end_request: I/O error, dev mtdblock1, sector 192
[ 15.071807] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071838] end_request: I/O error, dev mtdblock1, sector 200
[ 15.071838] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071868] end_request: I/O error, dev mtdblock1, sector 208
[ 15.071868] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071899] end_request: I/O error, dev mtdblock1, sector 216
[ 15.071899] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071929] end_request: I/O error, dev mtdblock1, sector 224
[ 15.071929] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071960] end_request: I/O error, dev mtdblock1, sector 232
[ 15.071960] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071990] end_request: I/O error, dev mtdblock1, sector 240
[ 15.072021] msm_nand_read_oob: unsupported ops->len, 512
[ 15.072021] end_request: I/O error, dev mtdblock1, sector 248
[ 15.072052] msm_nand_read_oob: unsupported ops->len, 512
[ 15.072052] end_request: I/O error, dev mtdblock1, sector 0
[ 15.083251] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083282] end_request: I/O error, dev mtdblock2, sector 0
[ 15.083343] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083343] end_request: I/O error, dev mtdblock2, sector 8
[ 15.083374] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083404] end_request: I/O error, dev mtdblock2, sector 16
[ 15.083404] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083435] end_request: I/O error, dev mtdblock2, sector 24
[ 15.083435] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083465] end_request: I/O error, dev mtdblock2, sector 32
[ 15.083465] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083496] end_request: I/O error, dev mtdblock2, sector 40
[ 15.083496] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083526] end_request: I/O error, dev mtdblock2, sector 48
[ 15.083526] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083557] end_request: I/O error, dev mtdblock2, sector 56
[ 15.083557] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083587] end_request: I/O error, dev mtdblock2, sector 64
[ 15.083587] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083618] end_request: I/O error, dev mtdblock2, sector 72
[ 15.083618] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083648] end_request: I/O error, dev mtdblock2, sector 80
[ 15.083648] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083679] end_request: I/O error, dev mtdblock2, sector 88
[ 15.083679] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083709] end_request: I/O error, dev mtdblock2, sector 96
[ 15.083709] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083740] end_request: I/O error, dev mtdblock2, sector 104
[ 15.083740] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083770] end_request: I/O error, dev mtdblock2, sector 112
[ 15.083770] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083801] end_request: I/O error, dev mtdblock2, sector 120
[ 15.083801] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083831] end_request: I/O error, dev mtdblock2, sector 128
[ 15.083831] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083862] end_request: I/O error, dev mtdblock2, sector 136
[ 15.083862] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083892] end_request: I/O error, dev mtdblock2, sector 144
[ 15.083892] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083923] end_request: I/O error, dev mtdblock2, sector 152
[ 15.083923] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083953] end_request: I/O error, dev mtdblock2, sector 160
[ 15.083953] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083984] end_request: I/O error, dev mtdblock2, sector 168
[ 15.083984] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084014] end_request: I/O error, dev mtdblock2, sector 176
[ 15.084014] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084045] end_request: I/O error, dev mtdblock2, sector 184
[ 15.084045] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084075] end_request: I/O error, dev mtdblock2, sector 192
[ 15.084075] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084106] end_request: I/O error, dev mtdblock2, sector 200
[ 15.084106] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084136] end_request: I/O error, dev mtdblock2, sector 208
[ 15.084136] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084167] end_request: I/O error, dev mtdblock2, sector 216
[ 15.084167] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084167] end_request: I/O error, dev mtdblock2, sector 224
[ 15.084197] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084197] end_request: I/O error, dev mtdblock2, sector 232
[ 15.084228] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084228] end_request: I/O error, dev mtdblock2, sector 240
[ 15.084259] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084289] end_request: I/O error, dev mtdblock2, sector 248
[ 15.084320] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084320] end_request: I/O error, dev mtdblock2, sector 0
[ 15.093261] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093292] end_request: I/O error, dev mtdblock3, sector 0
[ 15.093353] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093383] end_request: I/O error, dev mtdblock3, sector 8
[ 15.093383] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093414] end_request: I/O error, dev mtdblock3, sector 16
[ 15.093414] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093444] end_request: I/O error, dev mtdblock3, sector 24
[ 15.093444] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093475] end_request: I/O error, dev mtdblock3, sector 32
[ 15.093475] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093505] end_request: I/O error, dev mtdblock3, sector 40
[ 15.093505] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093536] end_request: I/O error, dev mtdblock3, sector 48
[ 15.093536] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093566] end_request: I/O error, dev mtdblock3, sector 56
[ 15.093566] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093597] end_request: I/O error, dev mtdblock3, sector 64
[ 15.093597] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093627] end_request: I/O error, dev mtdblock3, sector 72
[ 15.093627] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093658] end_request: I/O error, dev mtdblock3, sector 80
[ 15.093658] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093688] end_request: I/O error, dev mtdblock3, sector 88
[ 15.093688] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093719] end_request: I/O error, dev mtdblock3, sector 96
[ 15.093719] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093750] end_request: I/O error, dev mtdblock3, sector 104
[ 15.093750] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093780] end_request: I/O error, dev mtdblock3, sector 112
[ 15.093780] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093811] end_request: I/O error, dev mtdblock3, sector 120
[ 15.093811] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093841] end_request: I/O error, dev mtdblock3, sector 128
[ 15.093841] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093872] end_request: I/O error, dev mtdblock3, sector 136
[ 15.093872] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093902] end_request: I/O error, dev mtdblock3, sector 144
[ 15.093902] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093933] end_request: I/O error, dev mtdblock3, sector 152
[ 15.093933] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093963] end_request: I/O error, dev mtdblock3, sector 160
[ 15.093963] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093994] end_request: I/O error, dev mtdblock3, sector 168
[ 15.093994] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094024] end_request: I/O error, dev mtdblock3, sector 176
[ 15.094024] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094055] end_request: I/O error, dev mtdblock3, sector 184
[ 15.094055] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094085] end_request: I/O error, dev mtdblock3, sector 192
[ 15.094085] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094116] end_request: I/O error, dev mtdblock3, sector 200
[ 15.094116] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094146] end_request: I/O error, dev mtdblock3, sector 208
[ 15.094146] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094177] end_request: I/O error, dev mtdblock3, sector 216
[ 15.094177] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094207] end_request: I/O error, dev mtdblock3, sector 224
[ 15.094207] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094207] end_request: I/O error, dev mtdblock3, sector 232
[ 15.094238] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094238] end_request: I/O error, dev mtdblock3, sector 240
[ 15.094299] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094299] end_request: I/O error, dev mtdblock3, sector 248
[ 15.094329] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094329] end_request: I/O error, dev mtdblock3, sector 0
[ 15.103424] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103454] end_request: I/O error, dev mtdblock4, sector 0
[ 15.103515] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103546] end_request: I/O error, dev mtdblock4, sector 8
[ 15.103546] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103576] end_request: I/O error, dev mtdblock4, sector 16
[ 15.103576] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103607] end_request: I/O error, dev mtdblock4, sector 24
[ 15.103607] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103637] end_request: I/O error, dev mtdblock4, sector 32
[ 15.103637] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103668] end_request: I/O error, dev mtdblock4, sector 40
[ 15.103698] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103698] end_request: I/O error, dev mtdblock4, sector 48
[ 15.103729] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103729] end_request: I/O error, dev mtdblock4, sector 56
[ 15.103759] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103759] end_request: I/O error, dev mtdblock4, sector 64
[ 15.103790] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103790] end_request: I/O error, dev mtdblock4, sector 72
[ 15.103820] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103820] end_request: I/O error, dev mtdblock4, sector 80
[ 15.103851] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103851] end_request: I/O error, dev mtdblock4, sector 88
[ 15.103881] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103881] end_request: I/O error, dev mtdblock4, sector 96
[ 15.103912] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103912] end_request: I/O error, dev mtdblock4, sector 104
[ 15.103942] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103942] end_request: I/O error, dev mtdblock4, sector 112
[ 15.103973] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103973] end_request: I/O error, dev mtdblock4, sector 120
[ 15.104003] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104003] end_request: I/O error, dev mtdblock4, sector 128
[ 15.104034] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104034] end_request: I/O error, dev mtdblock4, sector 136
[ 15.104064] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104064] end_request: I/O error, dev mtdblock4, sector 144
[ 15.104095] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104095] end_request: I/O error, dev mtdblock4, sector 152
[ 15.104125] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104125] end_request: I/O error, dev mtdblock4, sector 160
[ 15.104156] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104156] end_request: I/O error, dev mtdblock4, sector 168
[ 15.104187] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104187] end_request: I/O error, dev mtdblock4, sector 176
[ 15.104217] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104217] end_request: I/O error, dev mtdblock4, sector 184
[ 15.104248] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104248] end_request: I/O error, dev mtdblock4, sector 192
[ 15.104248] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104278] end_request: I/O error, dev mtdblock4, sector 200
[ 15.104278] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104309] end_request: I/O error, dev mtdblock4, sector 208
[ 15.104309] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104339] end_request: I/O error, dev mtdblock4, sector 216
[ 15.104339] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104370] end_request: I/O error, dev mtdblock4, sector 224
[ 15.104370] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104400] end_request: I/O error, dev mtdblock4, sector 232
[ 15.104400] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104431] end_request: I/O error, dev mtdblock4, sector 240
[ 15.104461] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104461] end_request: I/O error, dev mtdblock4, sector 248
[ 15.104492] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104492] end_request: I/O error, dev mtdblock4, sector 0
[ 15.111450] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111480] end_request: I/O error, dev mtdblock5, sector 0
[ 15.111541] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111541] end_request: I/O error, dev mtdblock5, sector 8
[ 15.111572] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111602] end_request: I/O error, dev mtdblock5, sector 16
[ 15.111602] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111633] end_request: I/O error, dev mtdblock5, sector 24
[ 15.111633] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111663] end_request: I/O error, dev mtdblock5, sector 32
[ 15.111663] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111694] end_request: I/O error, dev mtdblock5, sector 40
[ 15.111694] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111724] end_request: I/O error, dev mtdblock5, sector 48
[ 15.111724] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111755] end_request: I/O error, dev mtdblock5, sector 56
[ 15.111755] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111785] end_request: I/O error, dev mtdblock5, sector 64
[ 15.111785] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111816] end_request: I/O error, dev mtdblock5, sector 72
[ 15.111816] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111846] end_request: I/O error, dev mtdblock5, sector 80
[ 15.111846] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111877] end_request: I/O error, dev mtdblock5, sector 88
[ 15.111877] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111907] end_request: I/O error, dev mtdblock5, sector 96
[ 15.111907] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111938] end_request: I/O error, dev mtdblock5, sector 104
[ 15.111938] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111968] end_request: I/O error, dev mtdblock5, sector 112
[ 15.111968] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111999] end_request: I/O error, dev mtdblock5, sector 120
[ 15.111999] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112030] end_request: I/O error, dev mtdblock5, sector 128
[ 15.112030] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112060] end_request: I/O error, dev mtdblock5, sector 136
[ 15.112060] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112091] end_request: I/O error, dev mtdblock5, sector 144
[ 15.112091] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112121] end_request: I/O error, dev mtdblock5, sector 152
[ 15.112121] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112152] end_request: I/O error, dev mtdblock5, sector 160
[ 15.112152] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112182] end_request: I/O error, dev mtdblock5, sector 168
[ 15.112182] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112213] end_request: I/O error, dev mtdblock5, sector 176
[ 15.112213] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112243] end_request: I/O error, dev mtdblock5, sector 184
[ 15.112243] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112274] end_request: I/O error, dev mtdblock5, sector 192
[ 15.112274] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112304] end_request: I/O error, dev mtdblock5, sector 200
[ 15.112304] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112335] end_request: I/O error, dev mtdblock5, sector 208
[ 15.112335] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112365] end_request: I/O error, dev mtdblock5, sector 216
[ 15.112365] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112396] end_request: I/O error, dev mtdblock5, sector 224
[ 15.112396] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112426] end_request: I/O error, dev mtdblock5, sector 232
[ 15.112426] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112426] end_request: I/O error, dev mtdblock5, sector 240
[ 15.112487] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112487] end_request: I/O error, dev mtdblock5, sector 248
[ 15.112518] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112518] end_request: I/O error, dev mtdblock5, sector 0
[ 16.861083] mmc0: Command timeout
[ 16.877197] mmc0: queuing CIS tuple 0x91 length 3
[ 16.877227] mmc0: new high speed SDIO card at address 0001
[ 16.891784] DHD: dongle ram size is set to 294912(orig 294912)
[ 18.248382] eth0 (): not using net_device_ops yet
[ 18.251770] eth0: Broadcom Dongle Host Driver mac=00:23:76:b0:e4:74
[ 18.581176] rmnet_open()
[ 18.581329] SMD: ch 11 1 -> 2
[ 18.626190] rmnet_open()
[ 18.626281] SMD: ch 12 1 -> 2
[ 18.670959] rmnet_open()
[ 18.671081] SMD: ch 13 1 -> 2
[ 27.485321] dummy0: no IPv6 routers present
[ 28.765319] rmnet0: no IPv6 routers present
[ 28.775299] rmnet2: no IPv6 routers present
[ 29.085327] eth0: no IPv6 routers present
[ 29.415344] rmnet1: no IPv6 routers present
[ 30.035278] enabling adb function
[ 30.035461] hsusb: ONLINE -> RESET
[ 30.035461] hsusb: reset controller
[ 30.075317] msm_hsusb_phy_reset: success
[ 30.225280] ulpi: write 0x0c to 0x31
[ 30.225280] ulpi: write 0x31 to 0x32
[ 30.225280] ulpi: write 0x1d to 0x0d
[ 30.225311] ulpi: write 0x1d to 0x10
[ 30.225311] ept #0 out max:64 head:ffa02000 bit:0
[ 30.225311] ept #1 out max:512 head:ffa02080 bit:1
[ 30.225341] ept #2 out max:512 head:ffa02100 bit:2
[ 30.225341] ept #3 out max:512 head:ffa02180 bit:3
[ 30.225372] ept #0 in max:64 head:ffa02040 bit:16
[ 30.225372] ept #1 in max:512 head:ffa020c0 bit:17
[ 30.225372] ept #2 in max:512 head:ffa02140 bit:18
[ 30.225402] ept #3 in max:512 head:ffa021c0 bit:19
[ 30.225433] usb_ept_queue_xfer() tried to queue request while offline
[ 30.226043] usb_ept_queue_xfer() tried to queue request while offline
[ 30.226074] usb_mass_storage usb_mass_storage: error in submission: bulk-out --> -19
[ 30.226104] usb_ept_queue_xfer() tried to queue request while offline
[ 30.226104] usb: notify offline
[ 30.226135] diag_configure() 0
[ 30.226135] msm_hsusb: enable pullup
[ 30.226165] hsusb: RESET -> ONLINE
[ 30.227661] usb: reset
[ 30.249572] lcdc_unblank: ()
[ 30.249572] samsung_oled_panel_unblank: +()
[ 30.545593] samsung_oled_panel_unblank: -()
[ 31.369720] usb: portchange USB_SPEED_FULL
[ 31.371612] usb: reset
[ 31.467193] usb: portchange USB_SPEED_FULL
[ 31.470367] usb: suspend
[ 31.604187] usb: reset
[ 31.606445] usb: portchange USB_SPEED_HIGH
[ 32.092620] usb: reset
[ 32.094879] usb: portchange USB_SPEED_HIGH
[ 32.256317] diag_configure() 1
[ 32.256317] ### notify_usb_connected(1) ###
ps auxwwwf
USER PID %CPU %MEM VSZ RSS TTY STAT START TIME COMMAND
root 2 0.0 0.0 0 0 ? S< 01:32 0:00 [kthreadd]
root 3 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [ksoftirqd/0]
root 4 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [watchdog/0]
root 5 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [events/0]
root 6 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [khelper]
root 7 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [suspend]
root 8 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [kblockd/0]
root 9 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [kmmcd]
root 10 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [bluetooth]
root 11 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [qmi]
root 12 0.0 0.0 0 0 ? D< 01:32 0:00 \_ [rpcrouter]
root 13 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [krpcserversd]
root 14 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [dock]
root 15 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [detection/0]
root 16 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [button/0]
root 17 0.0 0.0 0 0 ? S 01:32 0:00 \_ [pdflush]
root 18 0.0 0.0 0 0 ? S 01:32 0:00 \_ [pdflush]
root 19 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [kswapd0]
root 20 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [aio/0]
root 30 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [panel_on/0]
root 35 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [mtdblockd]
root 36 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [USB mass_storag]
root 37 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [synaptics_wq]
root 38 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [w1_bus_master1]
root 39 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [kstriped]
root 40 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [kondemand/0]
root 41 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [hid_compat]
root 44 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [krfcommd]
root 45 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [ds2784-battery.]
root 46 0.2 0.0 0 0 ? S< 01:32 0:05 \_ [mmcqd]
root 47 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [kjournald]
root 215 0.0 0.0 0 0 ? S 01:32 0:00 \_ [iscan_sysioc]
root 216 0.0 0.0 0 0 ? S 01:32 0:00 \_ [dhcp_sysioc]
root 218 0.0 0.0 0 0 ? S 01:32 0:00 \_ [dhd_watchdog]
root 219 0.0 0.0 0 0 ? S 01:32 0:00 \_ [dhd_dpc]
root 220 0.0 0.0 0 0 ? S 01:32 0:00 \_ [dhd_sysioc]
root 1 0.0 0.2 1760 616 ? Ss 01:32 0:00 init [5]
root 75 0.0 0.3 2052 664 ? S
root 213 0.0 0.3 2048 704 ? S< 01:32 0:00 \_ /sbin/udevd -d
root 217 0.0 0.3 2048 676 ? S< 01:32 0:00 \_ /sbin/udevd -d
dbus 111 0.0 0.5 2652 1188 ? Ss 01:32 0:00 dbus-daemon --system --fork
root 227 0.0 0.9 4264 2172 ? Ss 01:32 0:01 /usr/sbin/connmand -W nl80211,wext
root 230 0.0 0.2 1840 624 ? RNs 01:32 0:00 /sbin/syslogd -m 0
root 232 0.0 1.0 5336 2192 ? S 01:32 0:00 /sbin/wpa_supplicant -u
root 234 0.0 0.2 1760 452 ? SNs 01:32 0:00 /sbin/klogd -x
root 246 0.0 0.8 4484 1916 ? Ss 01:32 0:00 /usr/sbin/ofonod
root 248 0.0 0.6 3840 1500 ? Ss 01:32 0:00 /usr/sbin/bluetoothd
root 254 0.0 0.2 2856 632 ? S 01:32 0:00 /bin/bash /etc/rc.d/rc.sysinit
root 311 0.0 0.0 3352 168 ? Sl 01:32 0:00 \_ /sbin/adbd
root 477 0.0 0.7 2840 1568 pts/0 Ss 01:51 0:00 \_ /system/bin/sh -
root 1696 3.6 0.6 2740 1372 pts/0 S+ 02:02 0:00 \_ /bin/bash /usr/bin/mcinfo
root 1844 0.0 0.4 2524 896 pts/0 R+ 02:02 0:00 \_ ps auxwwwf
root 271 0.0 0.3 2740 828 ? S 01:32 0:00 /bin/sh /etc/rc5.d/S50sensord start
root 272 0.0 0.5 2732 1212 ? S 01:32 0:00 \_ /bin/bash -c ulimit -S -c 0 >/dev/null 2>&1 ; /usr/sbin/sensord
root 273 0.0 2.2 45832 4828 ? Sl 01:32 0:00 \_ /usr/sbin/sensord
root 276 0.0 1.8 9388 4096 ? S 01:32 0:00 /usr/bin/timed
root 283 0.0 0.4 5908 1076 ? Ss 01:32 0:00 /usr/sbin/sshd
root 289 0.0 0.2 1748 508 tty1 Ss+ 01:32 0:00 /sbin/mingetty --noclear tty1
meego 290 0.0 1.0 5264 2352 ? Ss 01:32 0:00 uxlaunch
root 292 0.0 0.1 3588 320 ? S 01:32 0:00 \_ uxlaunch
root 310 0.0 6.2 26560 13652 tty2 Ss+ 01:32 0:01 \_ /usr/bin/Xorg :0 -nolisten tcp -dpi 120 -noreset -auth /var/run/uxlaunch/Xauth-meego-LrfuNe vt2
meego 396 0.3 9.8 110428 21492 ? Sl 01:32 0:06 \_ /usr/bin/duihome -software &
meego 399 0.0 3.0 27272 6704 ? SNl 01:32 0:01 \_ /usr/bin/msyncd
meego 400 0.0 2.1 18300 4756 ? SN 01:32 0:00 \_ corewatcher-applet
meego 401 0.0 1.4 19976 3220 ? SN 01:32 0:00 \_ /usr/libexec/tracker-miner-fs
meego 320 0.0 0.3 4812 680 ? Ss 01:32 0:00 /usr/bin/ssh-agent
root 322 0.0 1.3 19736 2840 ? Sl 01:32 0:00 /usr/sbin/console-kit-daemon --no-daemon
meego 390 0.0 0.4 2672 928 ? Ss 01:32 0:00 dbus-daemon --fork --session --print-pid 9 --print-address 11
meego 393 0.0 0.8 7348 1764 ? S 01:32 0:00 /usr/libexec/gconfd-2
root 415 0.0 1.2 6588 2628 ? S 01:33 0:00 /usr/libexec/upowerd
meego 446 0.1 4.0 24628 8740 ? Sl 01:34 0:01 /usr/libexec/tracker-store
meego 449 0.0 1.2 25592 2828 ? Sl 01:34 0:00 /usr/libexec/tumblerd
fdisk -l
Disk /dev/mmcblk0: 4013 MB, 4013948928 bytes
124 heads, 62 sectors/track, 1019 cylinders
Units = cylinders of 7688 * 512 = 3936256 bytes
Disk identifier: 0x00029d6c
Device Boot Start End Blocks Id System
/dev/mmcblk0p1 1 131 503533 c W95 FAT32 (LBA)
/dev/mmcblk0p2 132 959 3182832 83 Linux
/dev/mmcblk0p3 960 1019 230640 82 Linux swap / Solaris
lsmod
Module Size Used by
bcm4329 167152 0
netstat -anp
Active Internet connections (servers and established)
Proto Recv-Q Send-Q Local Address Foreign Address State PID/Program name
tcp 0 0 127.0.0.1:5037 0.0.0.0:* LISTEN 311/adbd
tcp 0 0 0.0.0.0:53 0.0.0.0:* LISTEN 227/connmand
tcp 0 0 0.0.0.0:22 0.0.0.0:* LISTEN 283/sshd
tcp 0 0 :::22 :::* LISTEN 283/sshd
udp 0 0 0.0.0.0:53 0.0.0.0:* 227/connmand
Active UNIX domain sockets (servers and established)
Proto RefCnt Flags Type State I-Node PID/Program name Path
unix 2 [ ACC ] STREAM LISTENING 1578 320/ssh-agent /tmp/ssh-oxcfTRs319/agent.319
unix 2 [ ACC ] STREAM LISTENING 1556 311/adbd @jdwp-control
unix 2 [ ACC ] STREAM LISTENING 1676 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 2 [ ACC ] STREAM LISTENING 1080 248/bluetoothd /var/run/sdp
unix 2 [ ACC ] STREAM LISTENING 1083 248/bluetoothd @/org/bluez/audio
unix 2 [ ACC ] STREAM LISTENING 1549 310/Xorg @/tmp/.X11-unix/X0
unix 2 [ ] DGRAM 334 75/udevd @/org/kernel/udev/udevd
unix 2 [ ACC ] STREAM LISTENING 1450 273/sensord /tmp/sensord.sock
unix 2 [ ACC ] STREAM LISTENING 429 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 2 [ ACC ] STREAM LISTENING 1550 310/Xorg /tmp/.X11-unix/X0
unix 10 [ ] DGRAM 971 230/syslogd /dev/log
unix 3 [ ] STREAM CONNECTED 1915 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1914 449/tumblerd
unix 3 [ ] STREAM CONNECTED 1903 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1902 446/tracker-store
unix 3 [ ] STREAM CONNECTED 1890 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1889 401/tracker-miner-f
unix 3 [ ] STREAM CONNECTED 1790 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1789 415/upowerd
unix 3 [ ] STREAM CONNECTED 1785 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1784 415/upowerd
unix 3 [ ] STREAM CONNECTED 1772 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1771 399/msyncd
unix 3 [ ] STREAM CONNECTED 1750 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1749 396/duihome
unix 3 [ ] STREAM CONNECTED 1746 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1745 396/duihome
unix 3 [ ] STREAM CONNECTED 1738 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1737 399/msyncd
unix 3 [ ] STREAM CONNECTED 1736 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1735 399/msyncd
unix 3 [ ] STREAM CONNECTED 1733 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1732 396/duihome
unix 3 [ ] STREAM CONNECTED 1731 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1730 400/corewatcher-app
unix 3 [ ] STREAM CONNECTED 1729 310/Xorg @/tmp/.X11-unix/X0
unix 3 [ ] STREAM CONNECTED 1728 396/duihome
unix 3 [ ] STREAM CONNECTED 1725 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1724 400/corewatcher-app
unix 3 [ ] STREAM CONNECTED 1722 310/Xorg @/tmp/.X11-unix/X0
unix 3 [ ] STREAM CONNECTED 1721 400/corewatcher-app
unix 3 [ ] STREAM CONNECTED 1713 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1712 399/msyncd
unix 2 [ ] DGRAM 1710 399/msyncd
unix 3 [ ] STREAM CONNECTED 1691 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1690 393/gconfd-2
unix 2 [ ] DGRAM 1689 393/gconfd-2
unix 3 [ ] STREAM CONNECTED 1678 390/dbus-daemon
unix 3 [ ] STREAM CONNECTED 1677 390/dbus-daemon
unix 3 [ ] STREAM CONNECTED 1619 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1618 322/console-kit-dae
unix 3 [ ] STREAM CONNECTED 1594 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1593 322/console-kit-dae
unix 3 [ ] STREAM CONNECTED 1581 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1580 290/uxlaunch
unix 3 [ ] STREAM CONNECTED 1566 311/adbd
unix 3 [ ] STREAM CONNECTED 1565 311/adbd
unix 3 [ ] STREAM CONNECTED 1560 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1559 276/timed
unix 3 [ ] STREAM CONNECTED 1554 311/adbd
unix 3 [ ] STREAM CONNECTED 1553 311/adbd
unix 2 [ ] DGRAM 1526 290/uxlaunch
unix 3 [ ] STREAM CONNECTED 1505 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1504 273/sensord
unix 2 [ ] DGRAM 1460 276/timed
unix 3 [ ] STREAM CONNECTED 1076 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1075 248/bluetoothd
unix 2 [ ] DGRAM 1074 248/bluetoothd
unix 3 [ ] STREAM CONNECTED 1067 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1066 246/ofonod
unix 2 [ ] DGRAM 1065 246/ofonod
unix 2 [ ] DGRAM 1001 234/klogd
unix 2 [ ] DGRAM 992 227/connmand
unix 3 [ ] STREAM CONNECTED 942 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 937 232/wpa_supplicant
unix 3 [ ] STREAM CONNECTED 914 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 913 227/connmand
unix 3 [ ] STREAM CONNECTED 432 111/dbus-daemon
unix 3 [ ] STREAM CONNECTED 431 111/dbus-daemon
unix 3 [ ] DGRAM 339 75/udevd
unix 3 [ ] DGRAM 338 75/udevd
ifconfig -a
dummy0 Link encap:Ethernet HWaddr D6:65:36:E9:1E:68
inet6 addr: fe80::d465:36ff:fee9:1e68/64 Scope:Link
UP BROADCAST RUNNING NOARP MTU:1500 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:8 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:0 (0.0 b) TX bytes:3160 (3.0 KiB)
eth0 Link encap:Ethernet HWaddr 00:23:76:B0:E4:74
inet6 addr: fe80::223:76ff:feb0:e474/64 Scope:Link
UP BROADCAST MULTICAST MTU:1500 Metric:1
RX packets:12 errors:0 dropped:0 overruns:0 frame:0
TX packets:6 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:696 (696.0 b) TX bytes:492 (492.0 b)
ip6tnl0 Link encap:UNSPEC HWaddr 00-00-00-00-00-00-00-00-00-00-00-00-00-00-00-00
NOARP MTU:1460 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:0 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:0 (0.0 b) TX bytes:0 (0.0 b)
lo Link encap:Local Loopback
inet addr:127.0.0.1 Mask:255.0.0.0
inet6 addr: ::1/128 Scope:Host
UP LOOPBACK RUNNING MTU:16436 Metric:1
RX packets:4 errors:0 dropped:0 overruns:0 frame:0
TX packets:4 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:200 (200.0 b) TX bytes:200 (200.0 b)
rmnet0 Link encap:Ethernet HWaddr FE:6C:09:1E:0E:AF
inet6 addr: fe80::fc6c:9ff:fe1e:eaf/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:11 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:0 (0.0 b) TX bytes:3418 (3.3 KiB)
rmnet1 Link encap:Ethernet HWaddr D2:67:6D:C2:54:7B
inet6 addr: fe80::d067:6dff:fec2:547b/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:11 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:0 (0.0 b) TX bytes:3418 (3.3 KiB)
rmnet2 Link encap:Ethernet HWaddr CE:70:76:84:1E:DC
inet6 addr: fe80::cc70:76ff:fe84:1edc/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:11 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:0 (0.0 b) TX bytes:3418 (3.3 KiB)
sit0 Link encap:IPv6-in-IPv4
NOARP MTU:1480 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:0 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:0 (0.0 b) TX bytes:0 (0.0 b)
/proc/cmdline
board_mahimahi.disable_uart3=0 board_mahimahi.usb_h2w_sw=0 board_mahimahi.disable_sdcard=0 diag.enabled=0 board_mahimahi.debug_uart=0 smisize=0 androidboot.baseband=4.06.00.12_7 androidboot.cid=GOOGL001 androidboot.carrier=GOOGLE androidboot.mid=PB9910000 androidboot.keycaps=qwerty androidboot.mode=normal androidboot.serialno=HT015P803993 androidboot.bootloader=0.33.0012 init=/sbin/init rootwait root=/dev/mmcblk0p2 rootfstype=ext3 rw
/proc/cpuinfo
Processor : ARMv7 Processor rev 2 (v7l)
BogoMIPS : 509.54
Features : swp half thumb fastmult vfp edsp thumbee neon
CPU implementer : 0x51
CPU architecture: 7
CPU variant : 0x0
CPU part : 0x00f
CPU revision : 2
Hardware : mahimahi
Revision : 0081
Serial : 0000000000000000
/proc/devices
Character devices:
1 mem
4 /dev/vc/0
4 tty
5 /dev/tty
5 /dev/console
5 /dev/ptmx
7 vcs
10 misc
13 input
29 fb
81 video4linux
90 mtd
108 ppp
128 ptm
136 pts
216 rfcomm
250 msm_camera
251 ttyHS
252 vdec
253 oncrpc
254 smd
Block devices:
259 blkext
7 loop
31 mtdblock
179 mmc
254 device-mapper
/proc/diskstats
31 0 mtdblock0 27 54 648 0 0 0 0 0 0 0 0
31 1 mtdblock1 27 54 648 0 0 0 0 0 0 0 0
31 2 mtdblock2 27 54 648 0 0 0 0 0 0 0 0
31 3 mtdblock3 27 54 648 60 0 0 0 0 0 60 60
31 4 mtdblock4 27 54 648 0 0 0 0 0 0 0 0
31 5 mtdblock5 27 54 648 0 0 0 0 0 0 0 0
179 0 mmcblk0 3377 482 173140 28640 1433 4379 46496 1985690 0 153170 2014310
179 1 mmcblk0p1 14 173 386 400 0 0 0 0 0 160 400
179 2 mmcblk0p2 3344 247 172106 28170 1433 4379 46496 1985690 0 153110 2013840
179 3 mmcblk0p3 10 31 328 30 0 0 0 0 0 30 30
/proc/interrupts
CPU0
0: 98 msm smd_dev
1: 0 msm debug
5: 21373 msm smsm_dev
7: 15778 msm gp_timer
8: 0 msm dg_timer
19: 3 msm msm_mdp
20: 0 msm kgsl
21: 8929 msm msmdatamover
22: 0 msm smd_dsp
24: 943 msm msm-sdcc (cmd)
25: 300 msm msm-sdcc (pio)
26: 9727 msm msm-sdcc (cmd)
27: 1 msm msm-sdcc (pio)
34: 127630 msm msm_i2c
58: 14545 msm msm_hsusb
108: 1 msmgpio gpio_event_axis
122: 0 msmgpio microp_interrupt
124: 1 msmgpio gpio_event_axis
125: 1 msmgpio gpio_event_axis
127: 0 msmgpio gpio_kp
128: 0 msmgpio gpio_kp
129: 0 msmgpio gpio_kp
173: 1 msmgpio bt host_wake
177: 1 msmgpio capella_cm3602
179: 2 msmgpio synaptics-rmi-ts
181: 1 msmgpio gpio_keys
226: 1 msmgpio debug-wakeup
232: 1 msmgpio gpio_event_axis
239: 137 msmgpio bcmsdh_sdmmc
240: 0 msmgpio akm8973
Err: 0
/proc/meminfo
MemTotal: 217720 kB
MemFree: 80744 kB
Buffers: 7376 kB
Cached: 83612 kB
SwapCached: 0 kB
Active: 64388 kB
Inactive: 59896 kB
Active(anon): 33436 kB
Inactive(anon): 0 kB
Active(file): 30952 kB
Inactive(file): 59896 kB
Unevictable: 0 kB
Mlocked: 0 kB
SwapTotal: 0 kB
SwapFree: 0 kB
Dirty: 2044 kB
Writeback: 0 kB
AnonPages: 33316 kB
Mapped: 27632 kB
Slab: 9300 kB
SReclaimable: 6000 kB
SUnreclaim: 3300 kB
PageTables: 912 kB
NFS_Unstable: 0 kB
Bounce: 0 kB
WritebackTmp: 0 kB
CommitLimit: 108860 kB
Committed_AS: 178684 kB
VmallocTotal: 688128 kB
VmallocUsed: 88748 kB
VmallocChunk: 565244 kB
/proc/mounts
rootfs / rootfs rw 0 0
/dev/root / ext3 rw,errors=continue,data=ordered 0 0
/proc /proc proc rw 0 0
/sys /sys sysfs rw 0 0
none /dev tmpfs rw,mode=755 0 0
none /dev/pts devpts rw,gid=5,mode=620 0 0
tmpfs /var/lock tmpfs rw,size=4096k 0 0
tmpfs /var/run tmpfs rw,size=4096k 0 0
tmpfs /dev/shm tmpfs rw 0 0
tmpfs /home/meego/.mozilla tmpfs rw,size=20480k 0 0
none /sys/kernel/debug debugfs rw 0 0
/proc/partitions
major minor #blocks name
31 0 896 mtdblock0
31 1 5120 mtdblock1
31 2 2560 mtdblock2
31 3 148480 mtdblock3
31 4 97280 mtdblock4
31 5 200960 mtdblock5
179 0 3919872 mmcblk0
179 1 503533 mmcblk0p1
179 2 3182832 mmcblk0p2
179 3 230640 mmcblk0p3
/var/log/Xorg.0.log
[ 25.917]
X.Org X Server 1.9.0
Release Date: 2010-08-20
[ 25.917] X Protocol Version 11, Revision 0
[ 25.917] Build Operating System: Linux 2.6.31.14-0.1-desktop armv7l
[ 25.917] Current Operating System: Linux localhost.localdomain 2.6.29-01118-ga971bfd #21 PREEMPT Sun Oct 31 10:08:45 JST 2010 armv7l
[ 25.918] Kernel command line: board_mahimahi.disable_uart3=0 board_mahimahi.usb_h2w_sw=0 board_mahimahi.disable_sdcard=0 diag.enabled=0 board_mahimahi.debug_uart=0 smisize=0 androidboot.baseband=4.06.00.12_7 androidboot.cid=GOOGL001 androidboot.carrier=GOOGLE androidboot.mid=PB9910000 androidboot.keycaps=qwerty androidboot.mode=normal androidboot.serialno=HT015P803993 androidboot.bootloader=0.33.0012 init=/sbin/init rootwait root=/dev/mmcblk0p2 rootfstype=ext3 rw
[ 25.918] Build Date: 01 October 2010 11:46:43AM
[ 25.918] Build ID: xorg-x11-server 1.9.0-4.5
[ 25.918] Current version of pixman: 0.18.2
[ 25.918] Before reporting problems, check http://wiki.x.org
to make sure that you have the latest version.
[ 25.918] Markers: (--) probed, (**) from config file, (==) default setting,
(++) from command line, (!!) notice, (II) informational,
(WW) warning, (EE) error, (NI) not implemented, (??) unknown.
[ 25.919] (==) Log file: "/var/log/Xorg.0.log", Time: Sat Oct 30 01:32:57 2010
[ 26.348] (==) Using config directory: "/etc/X11/xorg.conf.d"
[ 26.349] (==) No Layout section. Using the first Screen section.
[ 26.349] (==) No screen section available. Using defaults.
[ 26.349] (**) |-->Screen "Default Screen Section" (0)
[ 26.349] (**) | |-->Monitor ""
[ 26.350] (==) No monitor specified for screen "Default Screen Section".
Using a default monitor configuration.
[ 26.351] (==) Automatically adding devices
[ 26.351] (==) Automatically enabling devices
[ 26.351] (==) FontPath set to:
catalogue:/etc/X11/fontpath.d,
built-ins
[ 26.351] (==) ModulePath set to "/usr/lib/xorg/modules"
[ 26.351] (II) The server relies on udev to provide the list of input devices.
If no devices become available, reconfigure udev or disable AutoAddDevices.
[ 26.351] (II) Loader magic: 0x19a8e4
[ 26.351] (II) Module ABI versions:
[ 26.351] X.Org ANSI C Emulation: 0.4
[ 26.351] X.Org Video Driver: 8.0
[ 26.351] X.Org XInput driver : 11.0
[ 26.351] X.Org Server Extension : 4.0
[ 26.352] (II) LoadModule: "extmod"
[ 26.587] (II) Loading /usr/lib/xorg/modules/extensions/libextmod.so
[ 26.588] (II) Module extmod: vendor="X.Org Foundation"
[ 26.588] compiled for 1.9.0, module version = 1.0.0
[ 26.588] Module class: X.Org Server Extension
[ 26.588] ABI class: X.Org Server Extension, version 4.0
[ 26.588] (II) Loading extension MIT-SCREEN-SAVER
[ 26.588] (II) Loading extension XFree86-VidModeExtension
[ 26.589] (II) Loading extension XFree86-DGA
[ 26.589] (II) Loading extension DPMS
[ 26.589] (II) Loading extension XVideo
[ 26.589] (II) Loading extension XVideo-MotionCompensation
[ 26.589] (II) Loading extension X-Resource
[ 26.589] (II) LoadModule: "dbe"
[ 26.591] (II) Loading /usr/lib/xorg/modules/extensions/libdbe.so
[ 26.592] (II) Module dbe: vendor="X.Org Foundation"
[ 26.592] compiled for 1.9.0, module version = 1.0.0
[ 26.592] Module class: X.Org Server Extension
[ 26.592] ABI class: X.Org Server Extension, version 4.0
[ 26.593] (II) Loading extension DOUBLE-BUFFER
[ 26.593] (II) LoadModule: "glx"
[ 26.595] (II) Loading /usr/lib/xorg/modules/extensions/libglx.so
[ 26.596] (II) Module glx: vendor="X.Org Foundation"
[ 26.596] compiled for 1.9.0, module version = 1.0.0
[ 26.596] ABI class: X.Org Server Extension, version 4.0
[ 26.596] (==) AIGLX enabled
[ 26.597] (II) Loading extension GLX
[ 26.597] (II) LoadModule: "record"
[ 26.599] (II) Loading /usr/lib/xorg/modules/extensions/librecord.so
[ 26.600] (II) Module record: vendor="X.Org Foundation"
[ 26.600] compiled for 1.9.0, module version = 1.13.0
[ 26.601] Module class: X.Org Server Extension
[ 26.601] ABI class: X.Org Server Extension, version 4.0
[ 26.601] (II) Loading extension RECORD
[ 26.601] (II) LoadModule: "dri"
[ 26.603] (II) Loading /usr/lib/xorg/modules/extensions/libdri.so
[ 26.605] (II) Module dri: vendor="X.Org Foundation"
[ 26.605] compiled for 1.9.0, module version = 1.0.0
[ 26.605] ABI class: X.Org Server Extension, version 4.0
[ 26.605] (II) Loading extension XFree86-DRI
[ 26.605] (II) LoadModule: "dri2"
[ 26.608] (II) Loading /usr/lib/xorg/modules/extensions/libdri2.so
[ 26.609] (II) Module dri2: vendor="X.Org Foundation"
[ 26.609] compiled for 1.9.0, module version = 1.2.0
[ 26.609] ABI class: X.Org Server Extension, version 4.0
[ 26.609] (II) Loading extension DRI2
[ 26.609] Primary device is not PCI
[ 26.609] (==) Matched fbdev as autoconfigured driver 0
[ 26.609] (==) Assigned the driver to the xf86ConfigLayout
[ 26.609] (II) LoadModule: "fbdev"
[ 26.614] (II) Loading /usr/lib/xorg/modules/drivers/fbdev_drv.so
[ 26.615] (II) Module fbdev: vendor="X.Org Foundation"
[ 26.615] compiled for 1.9.0, module version = 0.4.1
[ 26.615] ABI class: X.Org Video Driver, version 8.0
[ 26.615] (II) FBDEV: driver for framebuffer: fbdev
[ 26.615] (++) using VT number 2
[ 26.616] (WW) Falling back to old probe method for fbdev
[ 26.616] (II) Loading sub module "fbdevhw"
[ 26.616] (II) LoadModule: "fbdevhw"
[ 26.618] (II) Loading /usr/lib/xorg/modules/libfbdevhw.so
[ 26.641] (II) Module fbdevhw: vendor="X.Org Foundation"
[ 26.641] compiled for 1.9.0, module version = 0.0.2
[ 26.641] ABI class: X.Org Video Driver, version 8.0
[ 26.642] (II) FBDEV(0): using default device
[ 26.642] (WW) VGA arbiter: cannot open kernel arbiter, no multi-card support
[ 26.642] (II) FBDEV(0): Creating default Display subsection in Screen section
"Default Screen Section" for depth/fbbpp 16/16
[ 26.642] (==) FBDEV(0): Depth 16, (==) framebuffer bpp 16
[ 26.643] (==) FBDEV(0): RGB weight 565
[ 26.643] (==) FBDEV(0): Default visual is TrueColor
[ 26.647] (==) FBDEV(0): Using gamma correction (1.0, 1.0, 1.0)
[ 26.648] (II) FBDEV(0): hardware: msmfb (video memory: 4500kB)
[ 26.648] (II) FBDEV(0): checking modes against framebuffer device...
[ 26.648] (II) FBDEV(0): checking modes against monitor...
[ 26.648] (--) FBDEV(0): Virtual size is 480x800 (pitch 480)
[ 26.648] (**) FBDEV(0): Built-in mode "current"
[ 26.648] (++) FBDEV(0): DPI set to (120, 120)
[ 26.648] (II) Loading sub module "fb"
[ 26.648] (II) LoadModule: "fb"
[ 26.650] (II) Loading /usr/lib/xorg/modules/libfb.so
[ 26.659] (II) Module fb: vendor="X.Org Foundation"
[ 26.659] compiled for 1.9.0, module version = 1.0.0
[ 26.659] ABI class: X.Org ANSI C Emulation, version 0.4
[ 26.659] (**) FBDEV(0): using shadow framebuffer
[ 26.660] (II) Loading sub module "shadow"
[ 26.660] (II) LoadModule: "shadow"
[ 26.663] (II) Loading /usr/lib/xorg/modules/libshadow.so
[ 26.666] (II) Module shadow: vendor="X.Org Foundation"
[ 26.667] compiled for 1.9.0, module version = 1.1.0
[ 26.667] ABI class: X.Org ANSI C Emulation, version 0.4
[ 26.667] (EE) FBDEV(0): FBIOBLANK: Invalid argument
[ 27.016] (==) FBDEV(0): Backing store disabled
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (==) FBDEV(0): DPMS enabled
[ 27.026] (==) RandR enabled
[ 27.026] (II) Initializing built-in extension Generic Event Extension
[ 27.026] (II) Initializing built-in extension SHAPE
[ 27.026] (II) Initializing built-in extension MIT-SHM
[ 27.026] (II) Initializing built-in extension XInputExtension
[ 27.026] (II) Initializing built-in extension XTEST
[ 27.026] (II) Initializing built-in extension BIG-REQUESTS
[ 27.026] (II) Initializing built-in extension SYNC
[ 27.026] (II) Initializing built-in extension XKEYBOARD
[ 27.026] (II) Initializing built-in extension XC-MISC
[ 27.027] (II) Initializing built-in extension XFIXES
[ 27.027] (II) Initializing built-in extension RENDER
[ 27.027] (II) Initializing built-in extension RANDR
[ 27.027] (II) Initializing built-in extension COMPOSITE
[ 27.027] (II) Initializing built-in extension DAMAGE
[ 27.088] (II) AIGLX: Screen 0 is not DRI2 capable
[ 27.088] (II) AIGLX: Screen 0 is not DRI capable
[ 27.183] (II) AIGLX: Loaded and initialized /usr/lib/dri/swrast_dri.so
[ 27.183] (II) GLX: Initialized DRISWRAST GL provider for screen 0
[ 27.277] (II) XKB: reuse xkmfile /var/cache/xkb/server-B20D7FC79C7F597315E3E501AEF10E0D866E8E92.xkm
[ 27.405] (II) config/udev: Adding input device lightsensor-level (/dev/event0)
[ 27.406] (**) lightsensor-level: Applying InputClass "default"
[ 27.406] (II) LoadModule: "evdev"
[ 27.408] (II) Loading /usr/lib/xorg/modules/input/evdev_drv.so
[ 27.412] (II) Module evdev: vendor="X.Org Foundation"
[ 27.412] compiled for 1.9.0, module version = 2.4.99
[ 27.412] Module class: X.Org XInput Driver
[ 27.412] ABI class: X.Org XInput driver, version 11.0
[ 27.412] (**) lightsensor-level: always reports core events
[ 27.413] (**) lightsensor-level: Device: "/dev/event0"
[ 27.413] (--) lightsensor-level: Found absolute axes
[ 27.413] (II) lightsensor-level: Configuring as mouse
[ 27.413] (II) XINPUT: Adding extended input device "lightsensor-level" (type: MOUSE)
[ 27.414] (II) lightsensor-level: initialized for absolute axes.
[ 27.416] (II) config/udev: Adding input device h2w headset (/dev/event1)
[ 27.416] (**) h2w headset: Applying InputClass "default"
[ 27.416] (**) h2w headset: always reports core events
[ 27.416] (**) h2w headset: Device: "/dev/event1"
[ 27.417] (--) h2w headset: Found keys
[ 27.417] (II) h2w headset: Configuring as keyboard
[ 27.417] (II) XINPUT: Adding extended input device "h2w headset" (type: KEYBOARD)
[ 27.417] (**) Option "xkb_rules" "evdev"
[ 27.417] (**) Option "xkb_model" "evdev"
[ 27.417] (**) Option "xkb_layout" "us"
[ 27.438] (II) XKB: reuse xkmfile /var/cache/xkb/server-D378AD8F86E560F712A83EE36E4E5E92C595B9BD.xkm
[ 27.445] (II) config/udev: Adding input device synaptics-rmi-touchscreen (/dev/event2)
[ 27.445] (**) synaptics-rmi-touchscreen: Applying InputClass "default"
[ 27.446] (**) synaptics-rmi-touchscreen: always reports core events
[ 27.446] (**) synaptics-rmi-touchscreen: Device: "/dev/event2"
[ 27.446] (--) synaptics-rmi-touchscreen: Found 3 mouse buttons
[ 27.446] (--) synaptics-rmi-touchscreen: Found absolute axes
[ 27.446] (--) synaptics-rmi-touchscreen: Found x and y absolute axes
[ 27.446] (--) synaptics-rmi-touchscreen: Found absolute touchscreen
[ 27.446] (II) synaptics-rmi-touchscreen: Configuring as touchscreen
[ 27.446] (**) synaptics-rmi-touchscreen: YAxisMapping: buttons 4 and 5
[ 27.447] (**) synaptics-rmi-touchscreen: EmulateWheelButton: 4, EmulateWheelInertia: 10, EmulateWheelTimeout: 200
[ 27.447] (II) XINPUT: Adding extended input device "synaptics-rmi-touchscreen" (type: TOUCHSCREEN)
[ 27.447] (II) synaptics-rmi-touchscreen: initialized for absolute axes.
[ 27.449] (II) config/udev: Adding input device mahimahi-keypad (/dev/event3)
[ 27.449] (**) mahimahi-keypad: Applying InputClass "default"
[ 27.450] (**) mahimahi-keypad: always reports core events
[ 27.450] (**) mahimahi-keypad: Device: "/dev/event3"
[ 27.450] (--) mahimahi-keypad: Found keys
[ 27.450] (II) mahimahi-keypad: Configuring as keyboard
[ 27.450] (II) XINPUT: Adding extended input device "mahimahi-keypad" (type: KEYBOARD)
[ 27.450] (**) Option "xkb_rules" "evdev"
[ 27.450] (**) Option "xkb_model" "evdev"
[ 27.450] (**) Option "xkb_layout" "us"
[ 27.453] (II) config/udev: Adding input device mahimahi-nav (/dev/event4)
[ 27.453] (**) mahimahi-nav: Applying InputClass "default"
[ 27.454] (**) mahimahi-nav: always reports core events
[ 27.454] (**) mahimahi-nav: Device: "/dev/event4"
[ 27.454] (--) mahimahi-nav: Found 1 mouse buttons
[ 27.454] (--) mahimahi-nav: Found relative axes
[ 27.454] (--) mahimahi-nav: Found x and y relative axes
[ 27.454] (II) mahimahi-nav: Configuring as mouse
[ 27.454] (**) mahimahi-nav: YAxisMapping: buttons 4 and 5
[ 27.454] (**) mahimahi-nav: EmulateWheelButton: 4, EmulateWheelInertia: 10, EmulateWheelTimeout: 200
[ 27.454] (II) XINPUT: Adding extended input device "mahimahi-nav" (type: MOUSE)
[ 27.455] (**) mahimahi-nav: (accel) keeping acceleration scheme 1
[ 27.455] (**) mahimahi-nav: (accel) acceleration profile 0
[ 27.455] (**) mahimahi-nav: (accel) acceleration factor: 2.000
[ 27.455] (**) mahimahi-nav: (accel) acceleration threshold: 4
[ 27.455] (II) mahimahi-nav: initialized for relative axes.
[ 27.457] (II) config/udev: Adding input device proximity (/dev/event5)
[ 27.458] (**) proximity: Applying InputClass "default"
[ 27.458] (**) proximity: always reports core events
[ 27.458] (**) proximity: Device: "/dev/event5"
[ 27.458] (--) proximity: Found absolute axes
[ 27.458] (II) proximity: Configuring as mouse
[ 27.458] (II) XINPUT: Adding extended input device "proximity" (type: MOUSE)
[ 27.458] (II) proximity: initialized for absolute axes.
[ 27.460] (II) config/udev: Adding input device compass (/dev/event6)
[ 27.461] (**) compass: Applying InputClass "default"
[ 27.461] (**) compass: always reports core events
[ 27.461] (**) compass: Device: "/dev/event6"
[ 27.461] (--) compass: Found absolute axes
[ 27.461] (--) compass: Found x and y absolute axes
[ 27.461] (II) compass: Configuring as mouse
[ 27.462] (II) XINPUT: Adding extended input device "compass" (type: MOUSE)
[ 27.462] (II) compass: initialized for absolute axes.
[ 27.593] (EE) FBDEV(0): FBIOBLANK: Invalid argument
[ 627.616] (EE) FBDEV(0): FBIOBLANK: Invalid argument
[ 627.617] (EE) FBDEV(0): FBIOBLANK: Invalid argument
[ 627.618] (EE) FBDEV(0): FBIOBLANK: Invalid argument
Thank you.
Part2. Single boot: http://blog.mitsutaka.org/2010/11/meego-11-for-nexusone-status-part2-and.html
As you know, MeeGo could be worked on the NexusOne. It was v1.1 development release that time. Then I tried if MeeGo 1.1 final release could work on it. Of course, It could be work. and We've made it more responsive to running.
1. Linux kernel
zImage is loaded from PC via fastboot command. It uses the Android kernel for MSM.
$ git clone git://android.git.kernel.org/kernel/msm.git -b android-msm-2.6.32 android-msm-2.6.32
$ cd android-msm-2.6.32
Then We use a mahimahi_defconfig using as the base kernel configuration.
$ cp arch/arm/configs/mahimahi_defconfig .config
And customize it. When it boots via fastboot, we don't need initrd.
-CONFIG_BLK_DEV_INITRD=y
+# CONFIG_BLK_DEV_INITRD is not set
If you want to use wifi. You need to change the firmware path.
-CONFIG_BCM4329_FW_PATH="/system/etc/firmware/fw_bcm4329.bin"
+CONFIG_BCM4329_FW_PATH="/lib/firmware/fw_bcm4329.bin"
Any linux distribution uses X.Org as the X Window System. So we can need the Virtual Terminal.
-# CONFIG_VT is not set
+CONFIG_VT=y
+CONFIG_CONSOLE_TRANSLATIONS=y
+CONFIG_VT_CONSOLE=y
+CONFIG_VT_HW_CONSOLE_BINDING=y
Then, Preparing cross compiler. cross compiler uses prebuilt.git from Android git tree.
$ export PATH=$PATH:
Final is compiling.
$ make oldconfig ARCH=arm CROSS_COMPILE=arm-eabi-
$ make zImage modules ARCH=arm CROSS_COMPILE=arm-eabi-
2. Root Filesystem.
Of course, We use the MeeGo as a root filesystem. I created a kickstart file of NexusOne for using the mic2(Image Creator).
$ vi meego-handset-armv7l-nexusone-1.1.ks
lang en_US.UTF-8
keyboard us
timezone --utc America/Los_Angeles
auth --useshadow --enablemd5
part / --size=1600 --ondisk mmcblk0p --fstype=ext3
rootpw meego
xconfig --startxonboot
desktop --autologinuser=meego --defaultdesktop=DUI --session=/usr/bin/mcompositor
user --name meego --groups audio,video --password meego
repo --name=core --baseurl=http://repo.meego.com/MeeGo/releases/1.1/core/repos/armv7l/packages/ --save --debuginfo --source --gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-meego01
repo --name=handset --baseurl=http://repo.meego.com/MeeGo/releases/1.1/handset/repos/armv7l/packages/ --save --debuginfo --source --gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-meego01
repo --name=non-oss --baseurl=http://repo.meego.com/MeeGo/releases/1.1/non-oss/repos/armv7l/packages/ --save --debuginfo --source --gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-meego01
repo --name=updates-core --baseurl=http://repo.meego.com/MeeGo/updates/1.1/core/repos/armv7l/packages/ --save --debuginfo --source --gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-meego01
repo --name=updates-handset --baseurl=http://repo.meego.com/MeeGo/updates/1.1/handset/repos/armv7l/packages/ --save --debuginfo --source --gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-meego01
repo --name=updates-non-oss --baseurl=http://repo.meego.com/MeeGo/updates/1.1/non-oss/repos/armv7l/packages/ --save --debuginfo --source --gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-meego01
%packages
@MeeGo Core
@MeeGo Base
@Minimal MeeGo X Window System
@MeeGo Compliance
@MeeGo Handset Desktop
@MeeGo Handset Applications
@MeeGo Handset Applications Branding
@X for Handsets
@MeeGo Handset Base Support
# Some development tools
openssh-server
wget
strace
bootchart
gdb
gdb-gdbserver
# Some extra tools/libs
connman-test
xorg-x11-utils-xev
# http://bugs.meego.com/show_bug.cgi?id=5651
-meegotouch-inputmethodbridges
-meegotouch-inputmethodframework
-meegotouch-inputmethodkeyboard
-meegotouch-inputmethodengine
# For nexusone
xorg-x11-drv-fbdev
mesa-dri-swrast-driver
yum
yum-utils
tar
%end
%post
set -x
# Prelink not included because of following bug
# http://bugs.meego.com/show_bug.cgi?id=5217
# make sure there aren't core files lying around
rm -f /core*
# open serial line console for embedded system
echo "s0:235:respawn:/sbin/agetty -L 115200 ttyS2 vt100" >> /etc/inittab
# work around for poor key import UI in PackageKit
rm -f /var/lib/rpm/__db*
rpm --rebuilddb
# Set up sane defaults for mthemedaemon settings
Config_Src=`gconftool-2 --get-default-source`
gconftool-2 --direct --config-source $Config_Src \
-s -t string /meegotouch/theme/target NexusOne
# By default N900 has different value than Aava for showStatusBar
sed -i 's!showStatusBar=false!showStatusBar=true!g' /etc/meegotouch/devices.conf
# Temporary fix to the meego-handset-fixup rpm package
sed -i 's!N900!NexusOne!g' /etc/gconf/gconf.xml.defaults/%gconf-tree.xml
#sed -i 's!\/usr\/sbin\/meego-dm!\/usr\/bin\/xinit \/usr\/bin\/startdui!' /etc/inittab
echo "#x:5:respawn:/usr/bin/xinit /usr/bin/startdui" >>/etc/inittab
cat >>/etc/meegotouch/devices.conf <
resolutionX=480
resolutionY=800
ppiX=256
ppiY=256
showStatusBar=false
EOF
cat >/usr/bin/startdui <
#!/bin/sh
/usr/bin/mthemedaemon &
/usr/bin/sysuid -software -remote-theme &
/usr/bin/meego-im-uiserver -software -remote-theme &
/usr/bin/mdecorator -software -remote-theme &
/usr/bin/startphonesim
exec /usr/bin/duihome --desktop -software -remote-theme
chmod +x /usr/bin/startdui
cat >>/etc/rc.d/rc.sysinit <
# Power Management
echo 245000 >/sys/devices/system/cpu/cpu0/cpufreq/scaling_min_freq
echo 998400 >/sys/devices/system/cpu/cpu0/cpufreq/scaling_max_freq
echo ondemand >/sys/devices/system/cpu/cpu0/cpufreq/scaling_governor
echo 40000 >/sys/devices/system/cpu/cpufreq/ondemand/sampling_rate
# Wakelock debug
echo 7 >/sys/module/wakelock/parameters/debug_mask
echo 1 >/proc/sys/kernel/panic_on_oops
echo 0 >/proc/sys/kernel/hung_task_timeout_secs
echo 4 >/proc/cpu/alignment
echo 10000000 >/proc/sys/kernel/sched_latency_ns
echo 2000000 >/proc/sys/kernel/sched_wakeup_granularity_ns
echo 1 >/proc/sys/kernel/sched_compat_yield
echo 0 >/proc/sys/kernel/sched_child_runs_first
# Write value must be consistent with the above properties.
# Note that the driver only supports 6 slots, so we have HOME_APP at the
# same memory level as services.
echo 0,1,2,7,14,15 >/sys/module/lowmemorykiller/parameters/adj
echo 1 >/proc/sys/vm/overcommit_memory
echo 4 >/proc/sys/vm/min_free_order_shift
echo 1536,2048,4096,5120,5632,6144 >/sys/module/lowmemorykiller/parameters/minfree
# Set init its forked children's oom_adj.
echo -16 >/proc/1/oom_adj
# Tweak background writeout
echo 200 >/proc/sys/vm/dirty_expire_centisecs
echo 5 >/proc/sys/vm/dirty_background_ratio
mkdir -p /mnt/sdcard /mnt/system /mnt/cache /mnt/userdata
(sleep 5; /sbin/adbd) &
EOF
mkdir -p /system/bin
ln -s /bin/bash /system/bin/sh
swprogs="
/usr/share/applications/dialer.desktop
/usr/share/applications/duicontrolpanel.desktop
/usr/share/applications/meego-handset-calendar.desktop
/usr/share/applications/meego-handset-chat.desktop
/usr/share/applications/meego-handset-people.desktop
/usr/share/applications/meego-handset-video.desktop
/usr/share/applications/meegomusic.desktop
/usr/share/applications/meegophotos.desktop
/usr/share/applications/settings.desktop
/usr/share/applications/sms.desktop
/etc/xdg/autostart/applauncherd.desktop
/etc/xdg/autostart/mdecorator.desktop
/etc/xdg/autostart/meego-im-uiserver.desktop
/etc/xdg/autostart/meegotouch-systemui.desktop
"
for prog in $swprogs; do
sed -e "s/Exec=.*$/\0 -software/" -i $prog
done
sed 's!session=\/usr\/bin\/mcompositor!session=\/usr\/bin\/duihome -software \&!' -i /etc/sysconfig/uxlaunch
# Normal bootchart is only 30 long so we use this to get longer bootchart during startup when needed.
cat > /sbin/bootchartd-long << EOF
#!/bin/sh
exec /sbin/bootchartd -n 4000
EOF
chmod +x /sbin/bootchartd-long
# Temporary fix for BMC#8664 to get fennec startup time more reasonable.
mkdir -p /home/meego/.mozilla/
chown -R meego:meego /home/meego/.mozilla/
cat >>/etc/fstab << EOF
tmpfs /home/meego/.mozilla tmpfs size=20m 0 0
/dev/mmcblk0p1 /mnt/sdcard vfat defaults 0 0
/dev/mtdblock3 /mnt/system yaffs2 defaults 0 0
/dev/mtdblock4 /mnt/cache yaffs2 defaults 0 0
/dev/mtdblock5 /mnt/userdata yaffs2 defaults 0 0
EOF
%end
%post --nochroot
set -x
if [ -n "$IMG_NAME" ]; then
echo "BUILD: $IMG_NAME" >> $INSTALL_ROOT/etc/meego-release
fi
# Creating rootfs tar ball.
for dir in `mount | grep $INSTALL_ROOT\/ | awk '{ print $3 }' | sort -r`; do
umount $dir
done
outdir=`pwd`
(cd $INSTALL_ROOT; tar czvf $outdir/${IMG_NAME}-rootfs.tar.gz .)
%end
Rootfs tar ball is smarter then raw image or filesystem image. I used it. and It extract to you microSD card. Layout the microSD partition. /dev/mmcblk0p1 is used from Android. /dev/mmcblk0p2 is MeeGo rootfs.
# fdisk -l
Disk /dev/mmcblk0: 4013 MB, 4013948928 bytes
124 heads, 62 sectors/track, 1019 cylinders
Units = cylinders of 7688 * 512 = 3936256 bytes
Disk identifier: 0x00029d6c
Device Boot Start End Blocks Id System
/dev/mmcblk0p1 1 131 503533 c W95 FAT32 (LBA)
/dev/mmcblk0p2 132 959 3182832 83 Linux
3. Boot
The microSD card insert to NexusOne. And Boot up fastboot mode. Then run the following command. root= is MeeGo root filesystem.
$ fastboot -c 'init=/sbin/init rootwait root=/dev/mmcblk0p2 rootfstype=ext3 rw' boot zImage
creating boot image...
creating boot image - 2240512 bytes
downloading 'boot.img'... OKAY
booting... OKAY
Enjoy!
They are some messages.
dmesg
[ 0.000000] Initializing cgroup subsys cpu
[ 0.000000] Linux version 2.6.29-01118-ga971bfd (mitsutaka@localhost) (gcc version 4.4.0 (GCC) ) #21 PREEMPT Sun Oct 31 10:08:45 JST 2010
[ 0.000000] CPU: ARMv7 Processor [510f00f2] revision 2 (ARMv7), cr=10c5387f
[ 0.000000] CPU: VIPT nonaliasing data cache, VIVT ASID tagged instruction cache
[ 0.000000] Machine: mahimahi
[ 0.000000] Ignoring unrecognised tag 0x4d534d71
[ 0.000000] Ignoring unrecognised tag 0x4d534d72
[ 0.000000] Ignoring unrecognised tag 0x4d534d73
[ 0.000000] Ignoring unrecognised tag 0x4d534d74
[ 0.000000] Ignoring unrecognised tag 0x4d534d75
[ 0.000000] Ignoring unrecognised tag 0x4d534d76
[ 0.000000] Ignoring unrecognised tag 0x5441000a
[ 0.000000] Ignoring unrecognised tag 0x41387898
[ 0.000000] Memory policy: ECC disabled, Data cache writeback
[ 0.000000] On node 0 totalpages: 56064
[ 0.000000] free_area_init_node: node 0, pgdat c03e12e8, node_mem_map c0490000
[ 0.000000] Normal zone: 438 pages used for memmap
[ 0.000000] Normal zone: 0 pages reserved
[ 0.000000] Normal zone: 55626 pages, LIFO batch:15
[ 0.000000] Built 1 zonelists in Zone order, mobility grouping on. Total pages: 55626
[ 0.000000] Kernel command line: board_mahimahi.disable_uart3=0 board_mahimahi.usb_h2w_sw=0 board_mahimahi.disable_sdcard=0 diag.enabled=0 board_mahimahi.debug_uart=0 smisize=0 androidboot.baseband=4.06.00.12_7 androidboot.cid=GOOGL001 androidboot.carrier=GOOGLE androidboot.mid=PB9910000 androidboot.keycaps=qwerty androidboot.mode=normal androidboot.serialno=HT015P803993 androidboot.bootloader=0.33.0012 init=/sbin/init rootwait root=/dev/mmcblk0p2 rootfstype=ext3 rw
[ 0.000000] Unknown boot option `board_mahimahi.disable_uart3=0': ignoring
[ 0.000000] Unknown boot option `board_mahimahi.usb_h2w_sw=0': ignoring
[ 0.000000] Unknown boot option `androidboot.baseband=4.06.00.12_7': ignoring
[ 0.000000] Unknown boot option `androidboot.cid=GOOGL001': ignoring
[ 0.000000] Unknown boot option `androidboot.carrier=GOOGLE': ignoring
[ 0.000000] Unknown boot option `androidboot.mid=PB9910000': ignoring
[ 0.000000] Unknown boot option `androidboot.keycaps=qwerty': ignoring
[ 0.000000] Unknown boot option `androidboot.mode=normal': ignoring
[ 0.000000] Unknown boot option `androidboot.bootloader=0.33.0012': ignoring
[ 0.000000] PID hash table entries: 1024 (order: 10, 4096 bytes)
[ 0.000000] Console: colour dummy device 80x30
[ 0.000000] console [tty0] enabled
[ 0.000610] Dentry cache hash table entries: 32768 (order: 5, 131072 bytes)
[ 0.000946] Inode-cache hash table entries: 16384 (order: 4, 65536 bytes)
[ 0.012634] Memory: 219MB = 219MB total
[ 0.012695] Memory: 217344KB available (3656K code, 870K data, 100K init)
[ 0.013275] Calibrating delay loop... 509.54 BogoMIPS (lpj=2547712)
[ 0.239929] Mount-cache hash table entries: 512
[ 0.240844] Initializing cgroup subsys debug
[ 0.240875] Initializing cgroup subsys cpuacct
[ 0.240905] Initializing cgroup subsys freezer
[ 0.240936] CPU: Testing write buffer coherency: ok
[ 0.243591] net_namespace: 780 bytes
[ 0.244140] regulator: core version 0.5
[ 0.244445] NET: Registered protocol family 16
[ 0.245635] mahimahi_init() revision=129
[ 3.801177] mahimahi_init_mmc()+
[ 3.801544] mahimahi_init_mmc()-
[ 3.809417] bio: create slab
[ 3.810760] msm_i2c_probe
[ 3.810974] msm_i2c_probe: clk_ctl 35d, 100000 Hz
[ 3.812377] regulator: VDCDC1: 1000 <--> 1300 mV
[ 3.812591] regulator: VDCDC2: 1260 mV
[ 3.812774] regulator: VDCDC3: 800 <--> 3300 mV
[ 3.813018] regulator: LDO1: 1000 <--> 3150 mV
[ 3.813201] regulator: LDO2: 3300 mV
[ 3.815246] Bluetooth: Core ver 2.15
[ 3.815521] NET: Registered protocol family 31
[ 3.815551] Bluetooth: HCI device and connection manager initialized
[ 3.815582] Bluetooth: HCI socket layer initialized
[ 3.817169] NET: Registered protocol family 2
[ 3.817382] IP route cache hash table entries: 2048 (order: 1, 8192 bytes)
[ 3.817962] TCP established hash table entries: 8192 (order: 4, 65536 bytes)
[ 3.818176] TCP bind hash table entries: 8192 (order: 3, 32768 bytes)
[ 3.818267] TCP: Hash tables configured (established 8192 bind 8192)
[ 3.818298] TCP reno registered
[ 3.818634] NET: Registered protocol family 1
[ 3.819610] smd_init()
[ 3.819641] smd_core_init()
[ 3.819732] smd_core_init() done
[ 3.819763] msm_init_last_radio_log: last radio log is 40000 bytes long
[ 3.820281] smd_alloc_channel() cid=00 size=08192 'SMD_DS'
[ 3.820495] smd_alloc_channel() cid=01 size=08192 'SMD_DIAG'
[ 3.820678] smd_alloc_channel() cid=02 size=08192 'SMD_RPCCALL'
[ 3.820831] smd_alloc_channel() cid=07 size=32768 'SMD_DATA1'
[ 3.821044] smd_alloc_channel() cid=08 size=08192 'SMD_DATA2'
[ 3.821197] smd_alloc_channel() cid=09 size=08192 'SMD_DATA3'
[ 3.821411] smd_alloc_channel() cid=11 size=32768 'SMD_DATA5'
[ 3.821563] smd_alloc_channel() cid=12 size=32768 'SMD_DATA6'
[ 3.821746] smd_alloc_channel() cid=13 size=32768 'SMD_DATA7'
[ 3.821899] smd_alloc_channel() cid=15 size=08192 'SMD_DATA9'
[ 3.822082] smd_alloc_channel() cid=27 size=08192 'SMD_GPSNMEA'
[ 3.822265] smd_alloc_channel() cid=40 size=08192 'DSP_DIAG'
[ 3.822448] smd_alloc_channel() cid 41 does not exist
[ 3.822509] smd_alloc_channel() cid=42 size=08192 'DSP_DAL_AQ_VID'
[ 3.822662] smd_alloc_channel() cid=43 size=08192 'DSP_DAL_AQ_AUD'
[ 3.822845] smd_alloc_channel() cid=46 size=08192 'DSP_DAL00'
[ 3.822998] smd_alloc_channel() cid 47 does not exist
[ 3.823028] smd_alloc_channel() cid=48 size=08192 'SMD_DAL_AM_AUD'
[ 3.823211] smd_alloc_channel() cid=49 size=08192 'SMD_DAL00'
[ 3.823394] smd_alloc_channel() cid=50 size=08192 'SMD_DATA5_CNTL'
[ 3.823547] smd_alloc_channel() cid=51 size=08192 'SMD_DATA6_CNTL'
[ 3.823760] smd_alloc_channel() cid=52 size=08192 'SMD_DATA7_CNTL'
[ 3.825073] SMD: ch 2 1 -> 2
[ 3.825225] Switched to high resolution mode on CPU 0
[ 3.827972] mdp_probe: initialized
[ 3.828033] spi: SPI_CONFIG=8f
[ 3.828063] spi: SPI_IO_CONTROL=401
[ 3.828094] spi: SPI_OPERATIONAL=85
[ 3.828125] spi: SPI_ERROR_FLAGS_EN=7f
[ 3.828125] spi: SPI_ERROR_FLAGS=7f
[ 3.828155] -mahimahi_init_spi_hack()
[ 3.828552] Registered led device: lcd-backlight
[ 3.831054] mahimahi-microp 0-0066: microp version [0B][15]
[ 3.831542] input: lightsensor-level as /devices/virtual/input/input0
[ 3.831939] Registered led device: green
[ 3.832183] Registered led device: amber
[ 3.832366] Registered led device: red
[ 3.832580] Registered led device: blue
[ 3.832794] Registered led device: jogball-backlight
[ 3.832977] Registered led device: button-backlight
[ 3.833496] microp_function_initialize: als_kadc=0x4f, als_gadc=0xc0
[ 3.848602] flashlight_init
[ 3.848663] flashlight_probe
[ 3.848663] flashlight_setup_gpio
[ 3.848907] Registered led device: flashlight
[ 3.849609] smd_alloc_channel() cid 41 does not exist
[ 3.849639] smd_alloc_channel() cid 47 does not exist
[ 3.851470] H2W: htc_35mm_jack driver register
[ 3.852172] input: h2w headset as /devices/virtual/input/input1
[ 3.861419] ashmem: initialized
[ 3.862426] yaffs Oct 30 2010 22:16:35 Installing.
[ 3.866638] alg: No test for stdrng (krng)
[ 3.866760] io scheduler noop registered
[ 3.866790] io scheduler anticipatory registered (default)
[ 3.867462] +mddi_client_nt35399_init()
[ 3.867950] samsung_oled_panel_init: +()
[ 3.868255] samsung_oled_panel_init: -()
[ 3.868957] msmfb_probe() installing 480 x 800 panel
[ 3.869445] mdp_lcdc_probe: initialized
[ 3.882446] msm_serial: driver initialized
[ 3.882781] msm_serial_hs.0: ttyHS0 at MMIO 0xa0200000 (irq = 44) is a MSM HS UART
[ 3.883270] msm_serial_hs module loaded
[ 3.887481] loop: module loaded
[ 3.887603] pmem: 1 init
[ 3.888610] pmem_adsp: 1 init
[ 3.890472] pmem_camera: 1 init
[ 3.891296] Android kernel panic handler initialized (bind=crashdata)
[ 3.891357] PPP generic driver version 2.4.2
[ 3.891723] PPP Deflate Compression module registered
[ 3.891754] PPP BSD Compression module registered
[ 3.892639] PPP MPPE Compression module registered
[ 3.892669] NET: Registered protocol family 24
[ 3.893646] rmnet0 (): not using net_device_ops yet
[ 3.894287] rmnet1 (): not using net_device_ops yet
[ 3.894897] rmnet2 (): not using net_device_ops yet
[ 3.895538] Linux video capture interface: v2.00
[ 3.895690] msm_v4l2: msm_v4l2_init
[ 3.896179] s5k3e2fx_sensor_probe
[ 4.508972] allocated dma buffer at ffa01000, dma_addr 2d55e000
[ 4.509094] read CFG0 = aa5400c0, CFG1 = 6746a
[ 4.509124] CFG0 = e85408c0, CFG1 = 4745e
[ 4.509155] CFG0: cw/page=3 ud_sz=516 ecc_sz=10 spare_sz=0 num_addr_cycles=5
[ 4.509246] NAND_READ_ID = 5510bcad
[ 4.509399] status: e03120
[ 4.509429] nandid: 5510bcad maker ad device bc
[ 4.509490] CFG0: cw/page=3 ud_sz=512 ecc_sz=10 spare_sz=4
[ 4.509582] DEV_CMD1: f00f3000
[ 4.509643] <6>NAND_EBI2_ECC_BUF_CFG: 1ff
[ 4.509674] flash_id: 5510bcad size 20000000
[ 4.509704] Creating 6 MTD partitions on "msm_nand":
[ 4.509735] 0x000003ee0000-0x000003fc0000 : "misc"
[ 4.511718] 0x000004240000-0x000004740000 : "recovery"
[ 4.517822] 0x000004740000-0x0000049c0000 : "boot"
[ 4.521270] 0x0000049c0000-0x00000dac0000 : "system"
[ 4.674621] 0x00000dac0000-0x0000139c0000 : "cache"
[ 4.775482] 0x0000139c0000-0x00001fe00000 : "userdata"
[ 4.983428] usb_probe() io=ce060000, irq=58, dma=ffa02000(2d562000)
[ 4.984161] usb_function_register() 'adb'
[ 4.984375] usb_function_register() 'usb_mass_storage'
[ 4.984527] usb_function_register() 'diag'
[ 4.984558] msm_hsusb: functions bound. starting.
[ 4.984588] usb_bind_func() 'usb_mass_storage'
[ 4.985290] usb_mass_storage usb_mass_storage: Number of LUNs=1
[ 4.985382] usb_bind_func() 'adb'
[ 4.985382] adb_bind() cd55a878, cd55aa38
[ 4.985748] adb_bind() allocated 4 tx requests
[ 4.986267] usb_bind_func() 'diag'
[ 4.986755] SMD: ch 1 1 -> 2
[ 4.987426] hsusb: IDLE -> ONLINE
[ 4.987579] hsusb: reset controller
[ 4.987854] mahimahi_ts_power: power 1
[ 5.025329] msm_hsusb_phy_reset: success
[ 5.135864] msm_i2c msm_i2c.0: error, status 43c8
[ 5.135894] msm_i2c msm_i2c.0: Error during data xfer (-5)
[ 5.175323] ulpi: write 0x0c to 0x31
[ 5.175323] ulpi: write 0x31 to 0x32
[ 5.175354] ulpi: write 0x1d to 0x0d
[ 5.175384] ulpi: write 0x1d to 0x10
[ 5.175415] ept #0 out max:64 head:ffa02000 bit:0
[ 5.175415] ept #1 out max:512 head:ffa02080 bit:1
[ 5.175445] ept #2 out max:512 head:ffa02100 bit:2
[ 5.175476] ept #3 out max:512 head:ffa02180 bit:3
[ 5.175506] ept #0 in max:64 head:ffa02040 bit:16
[ 5.175537] ept #1 in max:512 head:ffa020c0 bit:17
[ 5.175567] ept #2 in max:512 head:ffa02140 bit:18
[ 5.175567] ept #3 in max:512 head:ffa021c0 bit:19
[ 5.175628] usb: notify offline
[ 5.175659] diag_configure() 0
[ 5.175659] msm_hsusb: enable pullup
[ 5.175689] hsusb: ONLINE -> OFFLINE
[ 5.175720] ### notify_usb_connected(0) ###
[ 5.175750] diag_configure() 0
[ 5.175750] msm_hsusb: disable pullup
[ 5.215332] msm_hsusb_phy_reset: success
[ 5.246032] synaptics_ts_probe: Product Major Version 1
[ 5.246704] synaptics_ts_probe: Product Minor Version 3
[ 5.247406] synaptics_ts_probe: product property 2
[ 5.248077] synaptics_ts_probe: device control 81
[ 5.248748] synaptics_ts_probe: interrupt enable 1
[ 5.250640] synaptics_ts_probe: 0xe0: 1 1 1 2 1 3 0 0
[ 5.251678] synaptics_ts_probe: Sensor properties 701
[ 5.254852] synaptics_ts_probe: max_x 4050, max_y 6822
[ 5.254882] synaptics_ts_probe: inactive_x -210 -168, inactive_y -127 -341
[ 5.254913] synaptics_ts_probe: snap_x 0-0 0-0, snap_y 0-0 0-0
[ 5.255310] input: synaptics-rmi-touchscreen as /devices/virtual/input/input2
[ 5.256072] synaptics_ts_probe: Start touchscreen synaptics-rmi-touchscreen in interrupt mode
[ 5.256927] GPIO Matrix Keypad Driver: Start keypad matrix for mahimahi-keypad... in interrupt mode
[ 5.257080] GPIO Input Driver: Start gpio inputs for mahimahi-keypad... in interrupt mode
[ 5.257751] input: mahimahi-keypad as /devices/virtual/input/input3
[ 5.258392] input: mahimahi-nav as /devices/virtual/input/input4
[ 5.258819] capella_cm3602_probe: probe
[ 5.258850] capella_cm3602_probe: allocating input device
[ 5.258911] capella_cm3602_probe: registering input device
[ 5.259277] input: proximity as /devices/virtual/input/input5
[ 5.259521] capella_cm3602_probe: registering misc device
[ 5.259735] capella_cm3602_setup
[ 5.259796] proximity 1
[ 5.260314] using input dev h2w headset for key reset
[ 5.260375] using input dev mahimahi-keypad for key reset
[ 5.260437] using input dev mahimahi-nav for key reset
[ 5.261505] using rtc device, msm_rtc, for alarms<6>rs30000048:00010000 rs30000048:00010000: rtc core: registered msm_rtc as rtc0
[ 5.261688] AKM8973 compass driver: init
[ 5.263183] input: compass as /devices/virtual/input/input6
[ 5.263946] a1026_init
[ 5.264373] Driver for 1-wire Dallas network protocol.
[ 5.265777] msm_i2c msm_i2c.0: error, status 43c8
[ 5.265838] msm_i2c msm_i2c.0: Error during data xfer (-5)
[ 5.265899] ds2482 0-0018: i2c write c3 87 failed, -5, retries left 5
[ 5.266265] msm_i2c msm_i2c.0: error, status 43c8
[ 5.266296] msm_i2c msm_i2c.0: Error during data xfer (-5)
[ 5.266357] ds2482 0-0018: i2c write c3 87 failed, -5, retries left 4
[ 5.266723] msm_i2c msm_i2c.0: error, status 43c8
[ 5.266754] msm_i2c msm_i2c.0: Error during data xfer (-5)
[ 5.266815] ds2482 0-0018: i2c write c3 87 failed, -5, retries left 3
[ 5.267150] msm_i2c msm_i2c.0: error, status 43c8
[ 5.267211] msm_i2c msm_i2c.0: Error during data xfer (-5)
[ 5.267242] ds2482 0-0018: i2c write c3 87 failed, -5, retries left 2
[ 5.267608] msm_i2c msm_i2c.0: error, status 43c8
[ 5.267669] msm_i2c msm_i2c.0: Error during data xfer (-5)
[ 5.267700] ds2482 0-0018: i2c write c3 87 failed, -5, retries left 1
[ 5.268066] msm_i2c msm_i2c.0: error, status 43c8
[ 5.268096] msm_i2c msm_i2c.0: Error during data xfer (-5)
[ 5.268157] ds2482 0-0018: i2c write c3 87 failed, -5, retries left 0
[ 5.269653] device-mapper: uevent: version 1.0.3
[ 5.270202] device-mapper: ioctl: 4.14.0-ioctl (2008-04-23) initialised: [email protected]
[ 5.270294] Bluetooth: HCI UART driver ver 2.2
[ 5.270324] Bluetooth: HCI H4 protocol initialized
[ 5.270355] Bluetooth: HCILL protocol initialized
[ 5.271697] mmc0: Qualcomm MSM SDCC at 0x00000000a0300000 irq 24,0 dma 8
[ 5.271759] mmc0: 4 bit data mode enabled
[ 5.271759] mmc0: MMC clock 144000 -> 50000000 Hz, PCLK 64000000 Hz
[ 5.271789] mmc0: Slot eject status = 1
[ 5.271820] mmc0: Power save feature enable = 1
[ 5.271850] mmc0: DM non-cached buffer at ffa04000, dma_addr 0x2d58e000
[ 5.271881] mmc0: DM cmd busaddr 0x2d58e000, cmdptr busaddr 0x2d58e300
[ 5.272796] mmc1: Qualcomm MSM SDCC at 0x00000000a0400000 irq 26,0 dma 8
[ 5.272827] mmc1: 4 bit data mode enabled
[ 5.272857] mmc1: MMC clock 144000 -> 50000000 Hz, PCLK 64000000 Hz
[ 5.272888] mmc1: Slot eject status = 0
[ 5.272918] mmc1: Power save feature enable = 1
[ 5.272918] mmc1: DM non-cached buffer at ffa05000, dma_addr 0x2d590000
[ 5.272949] mmc1: DM cmd busaddr 0x2d590000, cmdptr busaddr 0x2d590300
[ 5.274658] logger: created 64K log 'log_main'
[ 5.274902] logger: created 256K log 'log_events'
[ 5.275115] logger: created 64K log 'log_radio'
[ 5.275207] ram_console: got buffer at 3a00000, size 40000
[ 5.275390] ram_console: found existing buffer, size 28431, start 28431
[ 5.401641] console [ram-1] enabled
[ 5.455413] TCP cubic registered
[ 5.455993] NET: Registered protocol family 10
[ 5.457031] lo: Disabled Privacy Extensions
[ 5.458343] Mobile IPv6
[ 5.458618] IPv6 over IPv4 tunneling driver
[ 5.459625] sit0: Disabled Privacy Extensions
[ 5.460632] ip6tnl0: Disabled Privacy Extensions
[ 5.461059] NET: Registered protocol family 17
[ 5.461242] NET: Registered protocol family 15
[ 5.461547] Bluetooth: L2CAP ver 2.13
[ 5.461700] Bluetooth: L2CAP socket layer initialized
[ 5.461853] Bluetooth: SCO (Voice Link) ver 0.6
[ 5.462127] Bluetooth: SCO socket layer initialized
[ 5.463043] Bluetooth: RFCOMM socket layer initialized
[ 5.463439] Bluetooth: RFCOMM TTY layer initialized
[ 5.463592] Bluetooth: RFCOMM ver 1.11
[ 5.463745] Bluetooth: BNEP (Ethernet Emulation) ver 1.3
[ 5.464019] Bluetooth: HIDP (Human Interface Emulation) ver 1.2
[ 5.464355] ThumbEE CPU extension supported.
[ 5.465087] clock_late_init() disabled 18 unused clocks
[ 5.465423] mahimahi_wifi_init: start
[ 5.475402] VFP support v0.3: implementor 51 architecture 0 part 0f variant 0 rev 1
[ 5.480468] rs30000048:00010000 rs30000048:00010000: setting system clock to 2010-10-30 01:32:33 UTC (1288402353)
[ 5.480957] Waiting for root device /dev/mmcblk0p2...
[ 5.520751] mmc1: Command timeout
[ 5.526733] mmc1: Command timeout
[ 5.532745] mmc1: Command timeout
[ 5.538726] mmc1: Command timeout
[ 5.930267] batt: 100%, 4157 mV, 70 mA (5 avg), 30.0 C, 1361 mAh
[ 5.930633] batt: charging OFF [FULL]
[ 6.422637] mmc1: host does not support reading read-only switch. assuming write-enable.
[ 6.422851] mmc1: new high speed SDHC card at address 0007
[ 6.423675] mmcblk0: mmc1:0007 SD04G 3.73 GiB
[ 6.424133] mmcblk0: p1 p2 p3
[ 9.362518] cable_status_update: status=1
[ 9.385375] hsusb: OFFLINE -> ONLINE
[ 9.385650] hsusb: reset controller
[ 9.425354] msm_hsusb_phy_reset: success
[ 9.575347] ulpi: write 0x0c to 0x31
[ 9.575500] ulpi: write 0x31 to 0x32
[ 9.575653] ulpi: write 0x1d to 0x0d
[ 9.575897] ulpi: write 0x1d to 0x10
[ 9.576049] ept #0 out max:64 head:ffa02000 bit:0
[ 9.576202] ept #1 out max:512 head:ffa02080 bit:1
[ 9.576477] ept #2 out max:512 head:ffa02100 bit:2
[ 9.576629] ept #3 out max:512 head:ffa02180 bit:3
[ 9.576904] ept #0 in max:64 head:ffa02040 bit:16
[ 9.577056] ept #1 in max:512 head:ffa020c0 bit:17
[ 9.577331] ept #2 in max:512 head:ffa02140 bit:18
[ 9.577484] ept #3 in max:512 head:ffa021c0 bit:19
[ 9.577636] usb: notify offline
[ 9.577911] diag_configure() 0
[ 9.578063] msm_hsusb: enable pullup
[ 9.581359] usb: suspend
[ 9.715301] usb: reset
[ 9.717590] usb: portchange USB_SPEED_HIGH
[ 10.191284] usb: reset
[ 10.193542] usb: portchange USB_SPEED_HIGH
[ 10.366394] diag_configure() 1
[ 10.366546] ### notify_usb_connected(1) ###
[ 10.366790] usb_mass_storage usb_mass_storage: config #1
[ 11.330566] EXT3-fs warning: mounting fs with errors, running e2fsck is recommended
[ 11.330810] kjournald starting. Commit interval 5 seconds
[ 11.539764] EXT3 FS on mmcblk0p2, internal journal
[ 11.540039] EXT3-fs: recovery complete.
[ 11.750671] EXT3-fs: mounted filesystem with ordered data mode.
[ 11.750946] VFS: Mounted root (ext3 filesystem) on device 179:2.
[ 11.751434] Freeing init memory: 100K
[ 13.549499] udev: starting version 161
[ 13.959869] wifi_set_power = 1
[ 13.959869] mahimahi_wifi_power: 1
[ 14.318908] wifi_set_carddetect = 1
[ 14.318939] mahimahi_wifi_set_carddetect: 1
[ 14.318939] mmc0: card_present 1
[ 14.318939] mmc0: Slot status change detected (0 -> 1)
[ 14.322021]
[ 14.322021] Dongle Host Driver, version 4.218.161.0
[ 15.062774] msm_nand_read_oob: unsupported ops->len, 512
[ 15.062805] end_request: I/O error, dev mtdblock0, sector 0
[ 15.062835] Buffer I/O error on device mtdblock0, logical block 0
[ 15.062896] msm_nand_read_oob: unsupported ops->len, 512
[ 15.062896] end_request: I/O error, dev mtdblock0, sector 8
[ 15.062927] Buffer I/O error on device mtdblock0, logical block 1
[ 15.062927] msm_nand_read_oob: unsupported ops->len, 512
[ 15.062957] end_request: I/O error, dev mtdblock0, sector 16
[ 15.062957] Buffer I/O error on device mtdblock0, logical block 2
[ 15.062988] msm_nand_read_oob: unsupported ops->len, 512
[ 15.062988] end_request: I/O error, dev mtdblock0, sector 24
[ 15.063018] Buffer I/O error on device mtdblock0, logical block 3
[ 15.063018] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063049] end_request: I/O error, dev mtdblock0, sector 32
[ 15.063049] Buffer I/O error on device mtdblock0, logical block 4
[ 15.063079] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063079] end_request: I/O error, dev mtdblock0, sector 40
[ 15.063110] Buffer I/O error on device mtdblock0, logical block 5
[ 15.063110] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063140] end_request: I/O error, dev mtdblock0, sector 48
[ 15.063140] Buffer I/O error on device mtdblock0, logical block 6
[ 15.063171] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063171] end_request: I/O error, dev mtdblock0, sector 56
[ 15.063201] Buffer I/O error on device mtdblock0, logical block 7
[ 15.063201] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063232] end_request: I/O error, dev mtdblock0, sector 64
[ 15.063232] Buffer I/O error on device mtdblock0, logical block 8
[ 15.063262] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063262] end_request: I/O error, dev mtdblock0, sector 72
[ 15.063262] Buffer I/O error on device mtdblock0, logical block 9
[ 15.063293] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063293] end_request: I/O error, dev mtdblock0, sector 80
[ 15.063323] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063323] end_request: I/O error, dev mtdblock0, sector 88
[ 15.063354] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063354] end_request: I/O error, dev mtdblock0, sector 96
[ 15.063385] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063385] end_request: I/O error, dev mtdblock0, sector 104
[ 15.063415] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063415] end_request: I/O error, dev mtdblock0, sector 112
[ 15.063446] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063446] end_request: I/O error, dev mtdblock0, sector 120
[ 15.063476] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063476] end_request: I/O error, dev mtdblock0, sector 128
[ 15.063507] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063507] end_request: I/O error, dev mtdblock0, sector 136
[ 15.063537] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063537] end_request: I/O error, dev mtdblock0, sector 144
[ 15.063568] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063568] end_request: I/O error, dev mtdblock0, sector 152
[ 15.063598] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063598] end_request: I/O error, dev mtdblock0, sector 160
[ 15.063629] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063629] end_request: I/O error, dev mtdblock0, sector 168
[ 15.063659] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063659] end_request: I/O error, dev mtdblock0, sector 176
[ 15.063690] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063690] end_request: I/O error, dev mtdblock0, sector 184
[ 15.063720] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063720] end_request: I/O error, dev mtdblock0, sector 192
[ 15.063751] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063751] end_request: I/O error, dev mtdblock0, sector 200
[ 15.063781] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063781] end_request: I/O error, dev mtdblock0, sector 208
[ 15.063812] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063812] end_request: I/O error, dev mtdblock0, sector 216
[ 15.063842] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063842] end_request: I/O error, dev mtdblock0, sector 224
[ 15.063873] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063873] end_request: I/O error, dev mtdblock0, sector 232
[ 15.063903] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063903] end_request: I/O error, dev mtdblock0, sector 240
[ 15.063934] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063964] end_request: I/O error, dev mtdblock0, sector 248
[ 15.063964] msm_nand_read_oob: unsupported ops->len, 512
[ 15.063995] end_request: I/O error, dev mtdblock0, sector 0
[ 15.070983] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071014] end_request: I/O error, dev mtdblock1, sector 0
[ 15.071075] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071105] end_request: I/O error, dev mtdblock1, sector 8
[ 15.071105] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071136] end_request: I/O error, dev mtdblock1, sector 16
[ 15.071136] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071166] end_request: I/O error, dev mtdblock1, sector 24
[ 15.071166] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071197] end_request: I/O error, dev mtdblock1, sector 32
[ 15.071197] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071228] end_request: I/O error, dev mtdblock1, sector 40
[ 15.071228] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071258] end_request: I/O error, dev mtdblock1, sector 48
[ 15.071258] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071289] end_request: I/O error, dev mtdblock1, sector 56
[ 15.071289] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071319] end_request: I/O error, dev mtdblock1, sector 64
[ 15.071319] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071350] end_request: I/O error, dev mtdblock1, sector 72
[ 15.071350] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071380] end_request: I/O error, dev mtdblock1, sector 80
[ 15.071380] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071411] end_request: I/O error, dev mtdblock1, sector 88
[ 15.071411] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071441] end_request: I/O error, dev mtdblock1, sector 96
[ 15.071441] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071472] end_request: I/O error, dev mtdblock1, sector 104
[ 15.071472] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071502] end_request: I/O error, dev mtdblock1, sector 112
[ 15.071502] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071533] end_request: I/O error, dev mtdblock1, sector 120
[ 15.071533] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071563] end_request: I/O error, dev mtdblock1, sector 128
[ 15.071563] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071594] end_request: I/O error, dev mtdblock1, sector 136
[ 15.071594] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071624] end_request: I/O error, dev mtdblock1, sector 144
[ 15.071624] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071655] end_request: I/O error, dev mtdblock1, sector 152
[ 15.071655] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071685] end_request: I/O error, dev mtdblock1, sector 160
[ 15.071685] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071716] end_request: I/O error, dev mtdblock1, sector 168
[ 15.071716] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071746] end_request: I/O error, dev mtdblock1, sector 176
[ 15.071746] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071777] end_request: I/O error, dev mtdblock1, sector 184
[ 15.071777] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071807] end_request: I/O error, dev mtdblock1, sector 192
[ 15.071807] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071838] end_request: I/O error, dev mtdblock1, sector 200
[ 15.071838] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071868] end_request: I/O error, dev mtdblock1, sector 208
[ 15.071868] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071899] end_request: I/O error, dev mtdblock1, sector 216
[ 15.071899] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071929] end_request: I/O error, dev mtdblock1, sector 224
[ 15.071929] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071960] end_request: I/O error, dev mtdblock1, sector 232
[ 15.071960] msm_nand_read_oob: unsupported ops->len, 512
[ 15.071990] end_request: I/O error, dev mtdblock1, sector 240
[ 15.072021] msm_nand_read_oob: unsupported ops->len, 512
[ 15.072021] end_request: I/O error, dev mtdblock1, sector 248
[ 15.072052] msm_nand_read_oob: unsupported ops->len, 512
[ 15.072052] end_request: I/O error, dev mtdblock1, sector 0
[ 15.083251] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083282] end_request: I/O error, dev mtdblock2, sector 0
[ 15.083343] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083343] end_request: I/O error, dev mtdblock2, sector 8
[ 15.083374] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083404] end_request: I/O error, dev mtdblock2, sector 16
[ 15.083404] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083435] end_request: I/O error, dev mtdblock2, sector 24
[ 15.083435] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083465] end_request: I/O error, dev mtdblock2, sector 32
[ 15.083465] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083496] end_request: I/O error, dev mtdblock2, sector 40
[ 15.083496] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083526] end_request: I/O error, dev mtdblock2, sector 48
[ 15.083526] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083557] end_request: I/O error, dev mtdblock2, sector 56
[ 15.083557] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083587] end_request: I/O error, dev mtdblock2, sector 64
[ 15.083587] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083618] end_request: I/O error, dev mtdblock2, sector 72
[ 15.083618] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083648] end_request: I/O error, dev mtdblock2, sector 80
[ 15.083648] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083679] end_request: I/O error, dev mtdblock2, sector 88
[ 15.083679] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083709] end_request: I/O error, dev mtdblock2, sector 96
[ 15.083709] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083740] end_request: I/O error, dev mtdblock2, sector 104
[ 15.083740] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083770] end_request: I/O error, dev mtdblock2, sector 112
[ 15.083770] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083801] end_request: I/O error, dev mtdblock2, sector 120
[ 15.083801] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083831] end_request: I/O error, dev mtdblock2, sector 128
[ 15.083831] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083862] end_request: I/O error, dev mtdblock2, sector 136
[ 15.083862] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083892] end_request: I/O error, dev mtdblock2, sector 144
[ 15.083892] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083923] end_request: I/O error, dev mtdblock2, sector 152
[ 15.083923] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083953] end_request: I/O error, dev mtdblock2, sector 160
[ 15.083953] msm_nand_read_oob: unsupported ops->len, 512
[ 15.083984] end_request: I/O error, dev mtdblock2, sector 168
[ 15.083984] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084014] end_request: I/O error, dev mtdblock2, sector 176
[ 15.084014] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084045] end_request: I/O error, dev mtdblock2, sector 184
[ 15.084045] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084075] end_request: I/O error, dev mtdblock2, sector 192
[ 15.084075] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084106] end_request: I/O error, dev mtdblock2, sector 200
[ 15.084106] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084136] end_request: I/O error, dev mtdblock2, sector 208
[ 15.084136] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084167] end_request: I/O error, dev mtdblock2, sector 216
[ 15.084167] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084167] end_request: I/O error, dev mtdblock2, sector 224
[ 15.084197] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084197] end_request: I/O error, dev mtdblock2, sector 232
[ 15.084228] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084228] end_request: I/O error, dev mtdblock2, sector 240
[ 15.084259] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084289] end_request: I/O error, dev mtdblock2, sector 248
[ 15.084320] msm_nand_read_oob: unsupported ops->len, 512
[ 15.084320] end_request: I/O error, dev mtdblock2, sector 0
[ 15.093261] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093292] end_request: I/O error, dev mtdblock3, sector 0
[ 15.093353] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093383] end_request: I/O error, dev mtdblock3, sector 8
[ 15.093383] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093414] end_request: I/O error, dev mtdblock3, sector 16
[ 15.093414] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093444] end_request: I/O error, dev mtdblock3, sector 24
[ 15.093444] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093475] end_request: I/O error, dev mtdblock3, sector 32
[ 15.093475] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093505] end_request: I/O error, dev mtdblock3, sector 40
[ 15.093505] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093536] end_request: I/O error, dev mtdblock3, sector 48
[ 15.093536] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093566] end_request: I/O error, dev mtdblock3, sector 56
[ 15.093566] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093597] end_request: I/O error, dev mtdblock3, sector 64
[ 15.093597] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093627] end_request: I/O error, dev mtdblock3, sector 72
[ 15.093627] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093658] end_request: I/O error, dev mtdblock3, sector 80
[ 15.093658] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093688] end_request: I/O error, dev mtdblock3, sector 88
[ 15.093688] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093719] end_request: I/O error, dev mtdblock3, sector 96
[ 15.093719] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093750] end_request: I/O error, dev mtdblock3, sector 104
[ 15.093750] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093780] end_request: I/O error, dev mtdblock3, sector 112
[ 15.093780] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093811] end_request: I/O error, dev mtdblock3, sector 120
[ 15.093811] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093841] end_request: I/O error, dev mtdblock3, sector 128
[ 15.093841] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093872] end_request: I/O error, dev mtdblock3, sector 136
[ 15.093872] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093902] end_request: I/O error, dev mtdblock3, sector 144
[ 15.093902] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093933] end_request: I/O error, dev mtdblock3, sector 152
[ 15.093933] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093963] end_request: I/O error, dev mtdblock3, sector 160
[ 15.093963] msm_nand_read_oob: unsupported ops->len, 512
[ 15.093994] end_request: I/O error, dev mtdblock3, sector 168
[ 15.093994] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094024] end_request: I/O error, dev mtdblock3, sector 176
[ 15.094024] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094055] end_request: I/O error, dev mtdblock3, sector 184
[ 15.094055] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094085] end_request: I/O error, dev mtdblock3, sector 192
[ 15.094085] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094116] end_request: I/O error, dev mtdblock3, sector 200
[ 15.094116] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094146] end_request: I/O error, dev mtdblock3, sector 208
[ 15.094146] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094177] end_request: I/O error, dev mtdblock3, sector 216
[ 15.094177] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094207] end_request: I/O error, dev mtdblock3, sector 224
[ 15.094207] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094207] end_request: I/O error, dev mtdblock3, sector 232
[ 15.094238] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094238] end_request: I/O error, dev mtdblock3, sector 240
[ 15.094299] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094299] end_request: I/O error, dev mtdblock3, sector 248
[ 15.094329] msm_nand_read_oob: unsupported ops->len, 512
[ 15.094329] end_request: I/O error, dev mtdblock3, sector 0
[ 15.103424] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103454] end_request: I/O error, dev mtdblock4, sector 0
[ 15.103515] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103546] end_request: I/O error, dev mtdblock4, sector 8
[ 15.103546] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103576] end_request: I/O error, dev mtdblock4, sector 16
[ 15.103576] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103607] end_request: I/O error, dev mtdblock4, sector 24
[ 15.103607] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103637] end_request: I/O error, dev mtdblock4, sector 32
[ 15.103637] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103668] end_request: I/O error, dev mtdblock4, sector 40
[ 15.103698] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103698] end_request: I/O error, dev mtdblock4, sector 48
[ 15.103729] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103729] end_request: I/O error, dev mtdblock4, sector 56
[ 15.103759] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103759] end_request: I/O error, dev mtdblock4, sector 64
[ 15.103790] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103790] end_request: I/O error, dev mtdblock4, sector 72
[ 15.103820] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103820] end_request: I/O error, dev mtdblock4, sector 80
[ 15.103851] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103851] end_request: I/O error, dev mtdblock4, sector 88
[ 15.103881] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103881] end_request: I/O error, dev mtdblock4, sector 96
[ 15.103912] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103912] end_request: I/O error, dev mtdblock4, sector 104
[ 15.103942] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103942] end_request: I/O error, dev mtdblock4, sector 112
[ 15.103973] msm_nand_read_oob: unsupported ops->len, 512
[ 15.103973] end_request: I/O error, dev mtdblock4, sector 120
[ 15.104003] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104003] end_request: I/O error, dev mtdblock4, sector 128
[ 15.104034] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104034] end_request: I/O error, dev mtdblock4, sector 136
[ 15.104064] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104064] end_request: I/O error, dev mtdblock4, sector 144
[ 15.104095] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104095] end_request: I/O error, dev mtdblock4, sector 152
[ 15.104125] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104125] end_request: I/O error, dev mtdblock4, sector 160
[ 15.104156] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104156] end_request: I/O error, dev mtdblock4, sector 168
[ 15.104187] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104187] end_request: I/O error, dev mtdblock4, sector 176
[ 15.104217] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104217] end_request: I/O error, dev mtdblock4, sector 184
[ 15.104248] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104248] end_request: I/O error, dev mtdblock4, sector 192
[ 15.104248] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104278] end_request: I/O error, dev mtdblock4, sector 200
[ 15.104278] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104309] end_request: I/O error, dev mtdblock4, sector 208
[ 15.104309] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104339] end_request: I/O error, dev mtdblock4, sector 216
[ 15.104339] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104370] end_request: I/O error, dev mtdblock4, sector 224
[ 15.104370] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104400] end_request: I/O error, dev mtdblock4, sector 232
[ 15.104400] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104431] end_request: I/O error, dev mtdblock4, sector 240
[ 15.104461] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104461] end_request: I/O error, dev mtdblock4, sector 248
[ 15.104492] msm_nand_read_oob: unsupported ops->len, 512
[ 15.104492] end_request: I/O error, dev mtdblock4, sector 0
[ 15.111450] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111480] end_request: I/O error, dev mtdblock5, sector 0
[ 15.111541] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111541] end_request: I/O error, dev mtdblock5, sector 8
[ 15.111572] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111602] end_request: I/O error, dev mtdblock5, sector 16
[ 15.111602] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111633] end_request: I/O error, dev mtdblock5, sector 24
[ 15.111633] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111663] end_request: I/O error, dev mtdblock5, sector 32
[ 15.111663] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111694] end_request: I/O error, dev mtdblock5, sector 40
[ 15.111694] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111724] end_request: I/O error, dev mtdblock5, sector 48
[ 15.111724] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111755] end_request: I/O error, dev mtdblock5, sector 56
[ 15.111755] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111785] end_request: I/O error, dev mtdblock5, sector 64
[ 15.111785] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111816] end_request: I/O error, dev mtdblock5, sector 72
[ 15.111816] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111846] end_request: I/O error, dev mtdblock5, sector 80
[ 15.111846] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111877] end_request: I/O error, dev mtdblock5, sector 88
[ 15.111877] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111907] end_request: I/O error, dev mtdblock5, sector 96
[ 15.111907] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111938] end_request: I/O error, dev mtdblock5, sector 104
[ 15.111938] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111968] end_request: I/O error, dev mtdblock5, sector 112
[ 15.111968] msm_nand_read_oob: unsupported ops->len, 512
[ 15.111999] end_request: I/O error, dev mtdblock5, sector 120
[ 15.111999] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112030] end_request: I/O error, dev mtdblock5, sector 128
[ 15.112030] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112060] end_request: I/O error, dev mtdblock5, sector 136
[ 15.112060] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112091] end_request: I/O error, dev mtdblock5, sector 144
[ 15.112091] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112121] end_request: I/O error, dev mtdblock5, sector 152
[ 15.112121] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112152] end_request: I/O error, dev mtdblock5, sector 160
[ 15.112152] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112182] end_request: I/O error, dev mtdblock5, sector 168
[ 15.112182] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112213] end_request: I/O error, dev mtdblock5, sector 176
[ 15.112213] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112243] end_request: I/O error, dev mtdblock5, sector 184
[ 15.112243] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112274] end_request: I/O error, dev mtdblock5, sector 192
[ 15.112274] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112304] end_request: I/O error, dev mtdblock5, sector 200
[ 15.112304] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112335] end_request: I/O error, dev mtdblock5, sector 208
[ 15.112335] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112365] end_request: I/O error, dev mtdblock5, sector 216
[ 15.112365] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112396] end_request: I/O error, dev mtdblock5, sector 224
[ 15.112396] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112426] end_request: I/O error, dev mtdblock5, sector 232
[ 15.112426] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112426] end_request: I/O error, dev mtdblock5, sector 240
[ 15.112487] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112487] end_request: I/O error, dev mtdblock5, sector 248
[ 15.112518] msm_nand_read_oob: unsupported ops->len, 512
[ 15.112518] end_request: I/O error, dev mtdblock5, sector 0
[ 16.861083] mmc0: Command timeout
[ 16.877197] mmc0: queuing CIS tuple 0x91 length 3
[ 16.877227] mmc0: new high speed SDIO card at address 0001
[ 16.891784] DHD: dongle ram size is set to 294912(orig 294912)
[ 18.248382] eth0 (): not using net_device_ops yet
[ 18.251770] eth0: Broadcom Dongle Host Driver mac=00:23:76:b0:e4:74
[ 18.581176] rmnet_open()
[ 18.581329] SMD: ch 11 1 -> 2
[ 18.626190] rmnet_open()
[ 18.626281] SMD: ch 12 1 -> 2
[ 18.670959] rmnet_open()
[ 18.671081] SMD: ch 13 1 -> 2
[ 27.485321] dummy0: no IPv6 routers present
[ 28.765319] rmnet0: no IPv6 routers present
[ 28.775299] rmnet2: no IPv6 routers present
[ 29.085327] eth0: no IPv6 routers present
[ 29.415344] rmnet1: no IPv6 routers present
[ 30.035278] enabling adb function
[ 30.035461] hsusb: ONLINE -> RESET
[ 30.035461] hsusb: reset controller
[ 30.075317] msm_hsusb_phy_reset: success
[ 30.225280] ulpi: write 0x0c to 0x31
[ 30.225280] ulpi: write 0x31 to 0x32
[ 30.225280] ulpi: write 0x1d to 0x0d
[ 30.225311] ulpi: write 0x1d to 0x10
[ 30.225311] ept #0 out max:64 head:ffa02000 bit:0
[ 30.225311] ept #1 out max:512 head:ffa02080 bit:1
[ 30.225341] ept #2 out max:512 head:ffa02100 bit:2
[ 30.225341] ept #3 out max:512 head:ffa02180 bit:3
[ 30.225372] ept #0 in max:64 head:ffa02040 bit:16
[ 30.225372] ept #1 in max:512 head:ffa020c0 bit:17
[ 30.225372] ept #2 in max:512 head:ffa02140 bit:18
[ 30.225402] ept #3 in max:512 head:ffa021c0 bit:19
[ 30.225433] usb_ept_queue_xfer() tried to queue request while offline
[ 30.226043] usb_ept_queue_xfer() tried to queue request while offline
[ 30.226074] usb_mass_storage usb_mass_storage: error in submission: bulk-out --> -19
[ 30.226104] usb_ept_queue_xfer() tried to queue request while offline
[ 30.226104] usb: notify offline
[ 30.226135] diag_configure() 0
[ 30.226135] msm_hsusb: enable pullup
[ 30.226165] hsusb: RESET -> ONLINE
[ 30.227661] usb: reset
[ 30.249572] lcdc_unblank: ()
[ 30.249572] samsung_oled_panel_unblank: +()
[ 30.545593] samsung_oled_panel_unblank: -()
[ 31.369720] usb: portchange USB_SPEED_FULL
[ 31.371612] usb: reset
[ 31.467193] usb: portchange USB_SPEED_FULL
[ 31.470367] usb: suspend
[ 31.604187] usb: reset
[ 31.606445] usb: portchange USB_SPEED_HIGH
[ 32.092620] usb: reset
[ 32.094879] usb: portchange USB_SPEED_HIGH
[ 32.256317] diag_configure() 1
[ 32.256317] ### notify_usb_connected(1) ###
ps auxwwwf
USER PID %CPU %MEM VSZ RSS TTY STAT START TIME COMMAND
root 2 0.0 0.0 0 0 ? S< 01:32 0:00 [kthreadd]
root 3 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [ksoftirqd/0]
root 4 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [watchdog/0]
root 5 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [events/0]
root 6 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [khelper]
root 7 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [suspend]
root 8 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [kblockd/0]
root 9 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [kmmcd]
root 10 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [bluetooth]
root 11 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [qmi]
root 12 0.0 0.0 0 0 ? D< 01:32 0:00 \_ [rpcrouter]
root 13 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [krpcserversd]
root 14 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [dock]
root 15 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [detection/0]
root 16 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [button/0]
root 17 0.0 0.0 0 0 ? S 01:32 0:00 \_ [pdflush]
root 18 0.0 0.0 0 0 ? S 01:32 0:00 \_ [pdflush]
root 19 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [kswapd0]
root 20 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [aio/0]
root 30 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [panel_on/0]
root 35 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [mtdblockd]
root 36 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [USB mass_storag]
root 37 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [synaptics_wq]
root 38 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [w1_bus_master1]
root 39 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [kstriped]
root 40 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [kondemand/0]
root 41 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [hid_compat]
root 44 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [krfcommd]
root 45 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [ds2784-battery.]
root 46 0.2 0.0 0 0 ? S< 01:32 0:05 \_ [mmcqd]
root 47 0.0 0.0 0 0 ? S< 01:32 0:00 \_ [kjournald]
root 215 0.0 0.0 0 0 ? S 01:32 0:00 \_ [iscan_sysioc]
root 216 0.0 0.0 0 0 ? S 01:32 0:00 \_ [dhcp_sysioc]
root 218 0.0 0.0 0 0 ? S 01:32 0:00 \_ [dhd_watchdog]
root 219 0.0 0.0 0 0 ? S 01:32 0:00 \_ [dhd_dpc]
root 220 0.0 0.0 0 0 ? S 01:32 0:00 \_ [dhd_sysioc]
root 1 0.0 0.2 1760 616 ? Ss 01:32 0:00 init [5]
root 75 0.0 0.3 2052 664 ? S
root 213 0.0 0.3 2048 704 ? S< 01:32 0:00 \_ /sbin/udevd -d
root 217 0.0 0.3 2048 676 ? S< 01:32 0:00 \_ /sbin/udevd -d
dbus 111 0.0 0.5 2652 1188 ? Ss 01:32 0:00 dbus-daemon --system --fork
root 227 0.0 0.9 4264 2172 ? Ss 01:32 0:01 /usr/sbin/connmand -W nl80211,wext
root 230 0.0 0.2 1840 624 ? RNs 01:32 0:00 /sbin/syslogd -m 0
root 232 0.0 1.0 5336 2192 ? S 01:32 0:00 /sbin/wpa_supplicant -u
root 234 0.0 0.2 1760 452 ? SNs 01:32 0:00 /sbin/klogd -x
root 246 0.0 0.8 4484 1916 ? Ss 01:32 0:00 /usr/sbin/ofonod
root 248 0.0 0.6 3840 1500 ? Ss 01:32 0:00 /usr/sbin/bluetoothd
root 254 0.0 0.2 2856 632 ? S 01:32 0:00 /bin/bash /etc/rc.d/rc.sysinit
root 311 0.0 0.0 3352 168 ? Sl 01:32 0:00 \_ /sbin/adbd
root 477 0.0 0.7 2840 1568 pts/0 Ss 01:51 0:00 \_ /system/bin/sh -
root 1696 3.6 0.6 2740 1372 pts/0 S+ 02:02 0:00 \_ /bin/bash /usr/bin/mcinfo
root 1844 0.0 0.4 2524 896 pts/0 R+ 02:02 0:00 \_ ps auxwwwf
root 271 0.0 0.3 2740 828 ? S 01:32 0:00 /bin/sh /etc/rc5.d/S50sensord start
root 272 0.0 0.5 2732 1212 ? S 01:32 0:00 \_ /bin/bash -c ulimit -S -c 0 >/dev/null 2>&1 ; /usr/sbin/sensord
root 273 0.0 2.2 45832 4828 ? Sl 01:32 0:00 \_ /usr/sbin/sensord
root 276 0.0 1.8 9388 4096 ? S 01:32 0:00 /usr/bin/timed
root 283 0.0 0.4 5908 1076 ? Ss 01:32 0:00 /usr/sbin/sshd
root 289 0.0 0.2 1748 508 tty1 Ss+ 01:32 0:00 /sbin/mingetty --noclear tty1
meego 290 0.0 1.0 5264 2352 ? Ss 01:32 0:00 uxlaunch
root 292 0.0 0.1 3588 320 ? S 01:32 0:00 \_ uxlaunch
root 310 0.0 6.2 26560 13652 tty2 Ss+ 01:32 0:01 \_ /usr/bin/Xorg :0 -nolisten tcp -dpi 120 -noreset -auth /var/run/uxlaunch/Xauth-meego-LrfuNe vt2
meego 396 0.3 9.8 110428 21492 ? Sl 01:32 0:06 \_ /usr/bin/duihome -software &
meego 399 0.0 3.0 27272 6704 ? SNl 01:32 0:01 \_ /usr/bin/msyncd
meego 400 0.0 2.1 18300 4756 ? SN 01:32 0:00 \_ corewatcher-applet
meego 401 0.0 1.4 19976 3220 ? SN 01:32 0:00 \_ /usr/libexec/tracker-miner-fs
meego 320 0.0 0.3 4812 680 ? Ss 01:32 0:00 /usr/bin/ssh-agent
root 322 0.0 1.3 19736 2840 ? Sl 01:32 0:00 /usr/sbin/console-kit-daemon --no-daemon
meego 390 0.0 0.4 2672 928 ? Ss 01:32 0:00 dbus-daemon --fork --session --print-pid 9 --print-address 11
meego 393 0.0 0.8 7348 1764 ? S 01:32 0:00 /usr/libexec/gconfd-2
root 415 0.0 1.2 6588 2628 ? S 01:33 0:00 /usr/libexec/upowerd
meego 446 0.1 4.0 24628 8740 ? Sl 01:34 0:01 /usr/libexec/tracker-store
meego 449 0.0 1.2 25592 2828 ? Sl 01:34 0:00 /usr/libexec/tumblerd
fdisk -l
Disk /dev/mmcblk0: 4013 MB, 4013948928 bytes
124 heads, 62 sectors/track, 1019 cylinders
Units = cylinders of 7688 * 512 = 3936256 bytes
Disk identifier: 0x00029d6c
Device Boot Start End Blocks Id System
/dev/mmcblk0p1 1 131 503533 c W95 FAT32 (LBA)
/dev/mmcblk0p2 132 959 3182832 83 Linux
/dev/mmcblk0p3 960 1019 230640 82 Linux swap / Solaris
lsmod
Module Size Used by
bcm4329 167152 0
netstat -anp
Active Internet connections (servers and established)
Proto Recv-Q Send-Q Local Address Foreign Address State PID/Program name
tcp 0 0 127.0.0.1:5037 0.0.0.0:* LISTEN 311/adbd
tcp 0 0 0.0.0.0:53 0.0.0.0:* LISTEN 227/connmand
tcp 0 0 0.0.0.0:22 0.0.0.0:* LISTEN 283/sshd
tcp 0 0 :::22 :::* LISTEN 283/sshd
udp 0 0 0.0.0.0:53 0.0.0.0:* 227/connmand
Active UNIX domain sockets (servers and established)
Proto RefCnt Flags Type State I-Node PID/Program name Path
unix 2 [ ACC ] STREAM LISTENING 1578 320/ssh-agent /tmp/ssh-oxcfTRs319/agent.319
unix 2 [ ACC ] STREAM LISTENING 1556 311/adbd @jdwp-control
unix 2 [ ACC ] STREAM LISTENING 1676 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 2 [ ACC ] STREAM LISTENING 1080 248/bluetoothd /var/run/sdp
unix 2 [ ACC ] STREAM LISTENING 1083 248/bluetoothd @/org/bluez/audio
unix 2 [ ACC ] STREAM LISTENING 1549 310/Xorg @/tmp/.X11-unix/X0
unix 2 [ ] DGRAM 334 75/udevd @/org/kernel/udev/udevd
unix 2 [ ACC ] STREAM LISTENING 1450 273/sensord /tmp/sensord.sock
unix 2 [ ACC ] STREAM LISTENING 429 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 2 [ ACC ] STREAM LISTENING 1550 310/Xorg /tmp/.X11-unix/X0
unix 10 [ ] DGRAM 971 230/syslogd /dev/log
unix 3 [ ] STREAM CONNECTED 1915 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1914 449/tumblerd
unix 3 [ ] STREAM CONNECTED 1903 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1902 446/tracker-store
unix 3 [ ] STREAM CONNECTED 1890 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1889 401/tracker-miner-f
unix 3 [ ] STREAM CONNECTED 1790 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1789 415/upowerd
unix 3 [ ] STREAM CONNECTED 1785 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1784 415/upowerd
unix 3 [ ] STREAM CONNECTED 1772 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1771 399/msyncd
unix 3 [ ] STREAM CONNECTED 1750 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1749 396/duihome
unix 3 [ ] STREAM CONNECTED 1746 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1745 396/duihome
unix 3 [ ] STREAM CONNECTED 1738 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1737 399/msyncd
unix 3 [ ] STREAM CONNECTED 1736 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1735 399/msyncd
unix 3 [ ] STREAM CONNECTED 1733 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1732 396/duihome
unix 3 [ ] STREAM CONNECTED 1731 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1730 400/corewatcher-app
unix 3 [ ] STREAM CONNECTED 1729 310/Xorg @/tmp/.X11-unix/X0
unix 3 [ ] STREAM CONNECTED 1728 396/duihome
unix 3 [ ] STREAM CONNECTED 1725 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1724 400/corewatcher-app
unix 3 [ ] STREAM CONNECTED 1722 310/Xorg @/tmp/.X11-unix/X0
unix 3 [ ] STREAM CONNECTED 1721 400/corewatcher-app
unix 3 [ ] STREAM CONNECTED 1713 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1712 399/msyncd
unix 2 [ ] DGRAM 1710 399/msyncd
unix 3 [ ] STREAM CONNECTED 1691 390/dbus-daemon @/tmp/dbus-lqH3W1UFxE
unix 3 [ ] STREAM CONNECTED 1690 393/gconfd-2
unix 2 [ ] DGRAM 1689 393/gconfd-2
unix 3 [ ] STREAM CONNECTED 1678 390/dbus-daemon
unix 3 [ ] STREAM CONNECTED 1677 390/dbus-daemon
unix 3 [ ] STREAM CONNECTED 1619 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1618 322/console-kit-dae
unix 3 [ ] STREAM CONNECTED 1594 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1593 322/console-kit-dae
unix 3 [ ] STREAM CONNECTED 1581 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1580 290/uxlaunch
unix 3 [ ] STREAM CONNECTED 1566 311/adbd
unix 3 [ ] STREAM CONNECTED 1565 311/adbd
unix 3 [ ] STREAM CONNECTED 1560 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1559 276/timed
unix 3 [ ] STREAM CONNECTED 1554 311/adbd
unix 3 [ ] STREAM CONNECTED 1553 311/adbd
unix 2 [ ] DGRAM 1526 290/uxlaunch
unix 3 [ ] STREAM CONNECTED 1505 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1504 273/sensord
unix 2 [ ] DGRAM 1460 276/timed
unix 3 [ ] STREAM CONNECTED 1076 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1075 248/bluetoothd
unix 2 [ ] DGRAM 1074 248/bluetoothd
unix 3 [ ] STREAM CONNECTED 1067 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 1066 246/ofonod
unix 2 [ ] DGRAM 1065 246/ofonod
unix 2 [ ] DGRAM 1001 234/klogd
unix 2 [ ] DGRAM 992 227/connmand
unix 3 [ ] STREAM CONNECTED 942 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 937 232/wpa_supplicant
unix 3 [ ] STREAM CONNECTED 914 111/dbus-daemon /var/run/dbus/system_bus_socket
unix 3 [ ] STREAM CONNECTED 913 227/connmand
unix 3 [ ] STREAM CONNECTED 432 111/dbus-daemon
unix 3 [ ] STREAM CONNECTED 431 111/dbus-daemon
unix 3 [ ] DGRAM 339 75/udevd
unix 3 [ ] DGRAM 338 75/udevd
ifconfig -a
dummy0 Link encap:Ethernet HWaddr D6:65:36:E9:1E:68
inet6 addr: fe80::d465:36ff:fee9:1e68/64 Scope:Link
UP BROADCAST RUNNING NOARP MTU:1500 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:8 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:0 (0.0 b) TX bytes:3160 (3.0 KiB)
eth0 Link encap:Ethernet HWaddr 00:23:76:B0:E4:74
inet6 addr: fe80::223:76ff:feb0:e474/64 Scope:Link
UP BROADCAST MULTICAST MTU:1500 Metric:1
RX packets:12 errors:0 dropped:0 overruns:0 frame:0
TX packets:6 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:696 (696.0 b) TX bytes:492 (492.0 b)
ip6tnl0 Link encap:UNSPEC HWaddr 00-00-00-00-00-00-00-00-00-00-00-00-00-00-00-00
NOARP MTU:1460 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:0 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:0 (0.0 b) TX bytes:0 (0.0 b)
lo Link encap:Local Loopback
inet addr:127.0.0.1 Mask:255.0.0.0
inet6 addr: ::1/128 Scope:Host
UP LOOPBACK RUNNING MTU:16436 Metric:1
RX packets:4 errors:0 dropped:0 overruns:0 frame:0
TX packets:4 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:200 (200.0 b) TX bytes:200 (200.0 b)
rmnet0 Link encap:Ethernet HWaddr FE:6C:09:1E:0E:AF
inet6 addr: fe80::fc6c:9ff:fe1e:eaf/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:11 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:0 (0.0 b) TX bytes:3418 (3.3 KiB)
rmnet1 Link encap:Ethernet HWaddr D2:67:6D:C2:54:7B
inet6 addr: fe80::d067:6dff:fec2:547b/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:11 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:0 (0.0 b) TX bytes:3418 (3.3 KiB)
rmnet2 Link encap:Ethernet HWaddr CE:70:76:84:1E:DC
inet6 addr: fe80::cc70:76ff:fe84:1edc/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:11 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:0 (0.0 b) TX bytes:3418 (3.3 KiB)
sit0 Link encap:IPv6-in-IPv4
NOARP MTU:1480 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:0 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:0 (0.0 b) TX bytes:0 (0.0 b)
/proc/cmdline
board_mahimahi.disable_uart3=0 board_mahimahi.usb_h2w_sw=0 board_mahimahi.disable_sdcard=0 diag.enabled=0 board_mahimahi.debug_uart=0 smisize=0 androidboot.baseband=4.06.00.12_7 androidboot.cid=GOOGL001 androidboot.carrier=GOOGLE androidboot.mid=PB9910000 androidboot.keycaps=qwerty androidboot.mode=normal androidboot.serialno=HT015P803993 androidboot.bootloader=0.33.0012 init=/sbin/init rootwait root=/dev/mmcblk0p2 rootfstype=ext3 rw
/proc/cpuinfo
Processor : ARMv7 Processor rev 2 (v7l)
BogoMIPS : 509.54
Features : swp half thumb fastmult vfp edsp thumbee neon
CPU implementer : 0x51
CPU architecture: 7
CPU variant : 0x0
CPU part : 0x00f
CPU revision : 2
Hardware : mahimahi
Revision : 0081
Serial : 0000000000000000
/proc/devices
Character devices:
1 mem
4 /dev/vc/0
4 tty
5 /dev/tty
5 /dev/console
5 /dev/ptmx
7 vcs
10 misc
13 input
29 fb
81 video4linux
90 mtd
108 ppp
128 ptm
136 pts
216 rfcomm
250 msm_camera
251 ttyHS
252 vdec
253 oncrpc
254 smd
Block devices:
259 blkext
7 loop
31 mtdblock
179 mmc
254 device-mapper
/proc/diskstats
31 0 mtdblock0 27 54 648 0 0 0 0 0 0 0 0
31 1 mtdblock1 27 54 648 0 0 0 0 0 0 0 0
31 2 mtdblock2 27 54 648 0 0 0 0 0 0 0 0
31 3 mtdblock3 27 54 648 60 0 0 0 0 0 60 60
31 4 mtdblock4 27 54 648 0 0 0 0 0 0 0 0
31 5 mtdblock5 27 54 648 0 0 0 0 0 0 0 0
179 0 mmcblk0 3377 482 173140 28640 1433 4379 46496 1985690 0 153170 2014310
179 1 mmcblk0p1 14 173 386 400 0 0 0 0 0 160 400
179 2 mmcblk0p2 3344 247 172106 28170 1433 4379 46496 1985690 0 153110 2013840
179 3 mmcblk0p3 10 31 328 30 0 0 0 0 0 30 30
/proc/interrupts
CPU0
0: 98 msm smd_dev
1: 0 msm debug
5: 21373 msm smsm_dev
7: 15778 msm gp_timer
8: 0 msm dg_timer
19: 3 msm msm_mdp
20: 0 msm kgsl
21: 8929 msm msmdatamover
22: 0 msm smd_dsp
24: 943 msm msm-sdcc (cmd)
25: 300 msm msm-sdcc (pio)
26: 9727 msm msm-sdcc (cmd)
27: 1 msm msm-sdcc (pio)
34: 127630 msm msm_i2c
58: 14545 msm msm_hsusb
108: 1 msmgpio gpio_event_axis
122: 0 msmgpio microp_interrupt
124: 1 msmgpio gpio_event_axis
125: 1 msmgpio gpio_event_axis
127: 0 msmgpio gpio_kp
128: 0 msmgpio gpio_kp
129: 0 msmgpio gpio_kp
173: 1 msmgpio bt host_wake
177: 1 msmgpio capella_cm3602
179: 2 msmgpio synaptics-rmi-ts
181: 1 msmgpio gpio_keys
226: 1 msmgpio debug-wakeup
232: 1 msmgpio gpio_event_axis
239: 137 msmgpio bcmsdh_sdmmc
240: 0 msmgpio akm8973
Err: 0
/proc/meminfo
MemTotal: 217720 kB
MemFree: 80744 kB
Buffers: 7376 kB
Cached: 83612 kB
SwapCached: 0 kB
Active: 64388 kB
Inactive: 59896 kB
Active(anon): 33436 kB
Inactive(anon): 0 kB
Active(file): 30952 kB
Inactive(file): 59896 kB
Unevictable: 0 kB
Mlocked: 0 kB
SwapTotal: 0 kB
SwapFree: 0 kB
Dirty: 2044 kB
Writeback: 0 kB
AnonPages: 33316 kB
Mapped: 27632 kB
Slab: 9300 kB
SReclaimable: 6000 kB
SUnreclaim: 3300 kB
PageTables: 912 kB
NFS_Unstable: 0 kB
Bounce: 0 kB
WritebackTmp: 0 kB
CommitLimit: 108860 kB
Committed_AS: 178684 kB
VmallocTotal: 688128 kB
VmallocUsed: 88748 kB
VmallocChunk: 565244 kB
/proc/mounts
rootfs / rootfs rw 0 0
/dev/root / ext3 rw,errors=continue,data=ordered 0 0
/proc /proc proc rw 0 0
/sys /sys sysfs rw 0 0
none /dev tmpfs rw,mode=755 0 0
none /dev/pts devpts rw,gid=5,mode=620 0 0
tmpfs /var/lock tmpfs rw,size=4096k 0 0
tmpfs /var/run tmpfs rw,size=4096k 0 0
tmpfs /dev/shm tmpfs rw 0 0
tmpfs /home/meego/.mozilla tmpfs rw,size=20480k 0 0
none /sys/kernel/debug debugfs rw 0 0
/proc/partitions
major minor #blocks name
31 0 896 mtdblock0
31 1 5120 mtdblock1
31 2 2560 mtdblock2
31 3 148480 mtdblock3
31 4 97280 mtdblock4
31 5 200960 mtdblock5
179 0 3919872 mmcblk0
179 1 503533 mmcblk0p1
179 2 3182832 mmcblk0p2
179 3 230640 mmcblk0p3
/var/log/Xorg.0.log
[ 25.917]
X.Org X Server 1.9.0
Release Date: 2010-08-20
[ 25.917] X Protocol Version 11, Revision 0
[ 25.917] Build Operating System: Linux 2.6.31.14-0.1-desktop armv7l
[ 25.917] Current Operating System: Linux localhost.localdomain 2.6.29-01118-ga971bfd #21 PREEMPT Sun Oct 31 10:08:45 JST 2010 armv7l
[ 25.918] Kernel command line: board_mahimahi.disable_uart3=0 board_mahimahi.usb_h2w_sw=0 board_mahimahi.disable_sdcard=0 diag.enabled=0 board_mahimahi.debug_uart=0 smisize=0 androidboot.baseband=4.06.00.12_7 androidboot.cid=GOOGL001 androidboot.carrier=GOOGLE androidboot.mid=PB9910000 androidboot.keycaps=qwerty androidboot.mode=normal androidboot.serialno=HT015P803993 androidboot.bootloader=0.33.0012 init=/sbin/init rootwait root=/dev/mmcblk0p2 rootfstype=ext3 rw
[ 25.918] Build Date: 01 October 2010 11:46:43AM
[ 25.918] Build ID: xorg-x11-server 1.9.0-4.5
[ 25.918] Current version of pixman: 0.18.2
[ 25.918] Before reporting problems, check http://wiki.x.org
to make sure that you have the latest version.
[ 25.918] Markers: (--) probed, (**) from config file, (==) default setting,
(++) from command line, (!!) notice, (II) informational,
(WW) warning, (EE) error, (NI) not implemented, (??) unknown.
[ 25.919] (==) Log file: "/var/log/Xorg.0.log", Time: Sat Oct 30 01:32:57 2010
[ 26.348] (==) Using config directory: "/etc/X11/xorg.conf.d"
[ 26.349] (==) No Layout section. Using the first Screen section.
[ 26.349] (==) No screen section available. Using defaults.
[ 26.349] (**) |-->Screen "Default Screen Section" (0)
[ 26.349] (**) | |-->Monitor "
[ 26.350] (==) No monitor specified for screen "Default Screen Section".
Using a default monitor configuration.
[ 26.351] (==) Automatically adding devices
[ 26.351] (==) Automatically enabling devices
[ 26.351] (==) FontPath set to:
catalogue:/etc/X11/fontpath.d,
built-ins
[ 26.351] (==) ModulePath set to "/usr/lib/xorg/modules"
[ 26.351] (II) The server relies on udev to provide the list of input devices.
If no devices become available, reconfigure udev or disable AutoAddDevices.
[ 26.351] (II) Loader magic: 0x19a8e4
[ 26.351] (II) Module ABI versions:
[ 26.351] X.Org ANSI C Emulation: 0.4
[ 26.351] X.Org Video Driver: 8.0
[ 26.351] X.Org XInput driver : 11.0
[ 26.351] X.Org Server Extension : 4.0
[ 26.352] (II) LoadModule: "extmod"
[ 26.587] (II) Loading /usr/lib/xorg/modules/extensions/libextmod.so
[ 26.588] (II) Module extmod: vendor="X.Org Foundation"
[ 26.588] compiled for 1.9.0, module version = 1.0.0
[ 26.588] Module class: X.Org Server Extension
[ 26.588] ABI class: X.Org Server Extension, version 4.0
[ 26.588] (II) Loading extension MIT-SCREEN-SAVER
[ 26.588] (II) Loading extension XFree86-VidModeExtension
[ 26.589] (II) Loading extension XFree86-DGA
[ 26.589] (II) Loading extension DPMS
[ 26.589] (II) Loading extension XVideo
[ 26.589] (II) Loading extension XVideo-MotionCompensation
[ 26.589] (II) Loading extension X-Resource
[ 26.589] (II) LoadModule: "dbe"
[ 26.591] (II) Loading /usr/lib/xorg/modules/extensions/libdbe.so
[ 26.592] (II) Module dbe: vendor="X.Org Foundation"
[ 26.592] compiled for 1.9.0, module version = 1.0.0
[ 26.592] Module class: X.Org Server Extension
[ 26.592] ABI class: X.Org Server Extension, version 4.0
[ 26.593] (II) Loading extension DOUBLE-BUFFER
[ 26.593] (II) LoadModule: "glx"
[ 26.595] (II) Loading /usr/lib/xorg/modules/extensions/libglx.so
[ 26.596] (II) Module glx: vendor="X.Org Foundation"
[ 26.596] compiled for 1.9.0, module version = 1.0.0
[ 26.596] ABI class: X.Org Server Extension, version 4.0
[ 26.596] (==) AIGLX enabled
[ 26.597] (II) Loading extension GLX
[ 26.597] (II) LoadModule: "record"
[ 26.599] (II) Loading /usr/lib/xorg/modules/extensions/librecord.so
[ 26.600] (II) Module record: vendor="X.Org Foundation"
[ 26.600] compiled for 1.9.0, module version = 1.13.0
[ 26.601] Module class: X.Org Server Extension
[ 26.601] ABI class: X.Org Server Extension, version 4.0
[ 26.601] (II) Loading extension RECORD
[ 26.601] (II) LoadModule: "dri"
[ 26.603] (II) Loading /usr/lib/xorg/modules/extensions/libdri.so
[ 26.605] (II) Module dri: vendor="X.Org Foundation"
[ 26.605] compiled for 1.9.0, module version = 1.0.0
[ 26.605] ABI class: X.Org Server Extension, version 4.0
[ 26.605] (II) Loading extension XFree86-DRI
[ 26.605] (II) LoadModule: "dri2"
[ 26.608] (II) Loading /usr/lib/xorg/modules/extensions/libdri2.so
[ 26.609] (II) Module dri2: vendor="X.Org Foundation"
[ 26.609] compiled for 1.9.0, module version = 1.2.0
[ 26.609] ABI class: X.Org Server Extension, version 4.0
[ 26.609] (II) Loading extension DRI2
[ 26.609] Primary device is not PCI
[ 26.609] (==) Matched fbdev as autoconfigured driver 0
[ 26.609] (==) Assigned the driver to the xf86ConfigLayout
[ 26.609] (II) LoadModule: "fbdev"
[ 26.614] (II) Loading /usr/lib/xorg/modules/drivers/fbdev_drv.so
[ 26.615] (II) Module fbdev: vendor="X.Org Foundation"
[ 26.615] compiled for 1.9.0, module version = 0.4.1
[ 26.615] ABI class: X.Org Video Driver, version 8.0
[ 26.615] (II) FBDEV: driver for framebuffer: fbdev
[ 26.615] (++) using VT number 2
[ 26.616] (WW) Falling back to old probe method for fbdev
[ 26.616] (II) Loading sub module "fbdevhw"
[ 26.616] (II) LoadModule: "fbdevhw"
[ 26.618] (II) Loading /usr/lib/xorg/modules/libfbdevhw.so
[ 26.641] (II) Module fbdevhw: vendor="X.Org Foundation"
[ 26.641] compiled for 1.9.0, module version = 0.0.2
[ 26.641] ABI class: X.Org Video Driver, version 8.0
[ 26.642] (II) FBDEV(0): using default device
[ 26.642] (WW) VGA arbiter: cannot open kernel arbiter, no multi-card support
[ 26.642] (II) FBDEV(0): Creating default Display subsection in Screen section
"Default Screen Section" for depth/fbbpp 16/16
[ 26.642] (==) FBDEV(0): Depth 16, (==) framebuffer bpp 16
[ 26.643] (==) FBDEV(0): RGB weight 565
[ 26.643] (==) FBDEV(0): Default visual is TrueColor
[ 26.647] (==) FBDEV(0): Using gamma correction (1.0, 1.0, 1.0)
[ 26.648] (II) FBDEV(0): hardware: msmfb (video memory: 4500kB)
[ 26.648] (II) FBDEV(0): checking modes against framebuffer device...
[ 26.648] (II) FBDEV(0): checking modes against monitor...
[ 26.648] (--) FBDEV(0): Virtual size is 480x800 (pitch 480)
[ 26.648] (**) FBDEV(0): Built-in mode "current"
[ 26.648] (++) FBDEV(0): DPI set to (120, 120)
[ 26.648] (II) Loading sub module "fb"
[ 26.648] (II) LoadModule: "fb"
[ 26.650] (II) Loading /usr/lib/xorg/modules/libfb.so
[ 26.659] (II) Module fb: vendor="X.Org Foundation"
[ 26.659] compiled for 1.9.0, module version = 1.0.0
[ 26.659] ABI class: X.Org ANSI C Emulation, version 0.4
[ 26.659] (**) FBDEV(0): using shadow framebuffer
[ 26.660] (II) Loading sub module "shadow"
[ 26.660] (II) LoadModule: "shadow"
[ 26.663] (II) Loading /usr/lib/xorg/modules/libshadow.so
[ 26.666] (II) Module shadow: vendor="X.Org Foundation"
[ 26.667] compiled for 1.9.0, module version = 1.1.0
[ 26.667] ABI class: X.Org ANSI C Emulation, version 0.4
[ 26.667] (EE) FBDEV(0): FBIOBLANK: Invalid argument
[ 27.016] (==) FBDEV(0): Backing store disabled
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.017] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.018] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.019] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.020] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.021] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.022] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (EE) FBDEV(0): FBIOPUTCMAP: Invalid argument
[ 27.023] (==) FBDEV(0): DPMS enabled
[ 27.026] (==) RandR enabled
[ 27.026] (II) Initializing built-in extension Generic Event Extension
[ 27.026] (II) Initializing built-in extension SHAPE
[ 27.026] (II) Initializing built-in extension MIT-SHM
[ 27.026] (II) Initializing built-in extension XInputExtension
[ 27.026] (II) Initializing built-in extension XTEST
[ 27.026] (II) Initializing built-in extension BIG-REQUESTS
[ 27.026] (II) Initializing built-in extension SYNC
[ 27.026] (II) Initializing built-in extension XKEYBOARD
[ 27.026] (II) Initializing built-in extension XC-MISC
[ 27.027] (II) Initializing built-in extension XFIXES
[ 27.027] (II) Initializing built-in extension RENDER
[ 27.027] (II) Initializing built-in extension RANDR
[ 27.027] (II) Initializing built-in extension COMPOSITE
[ 27.027] (II) Initializing built-in extension DAMAGE
[ 27.088] (II) AIGLX: Screen 0 is not DRI2 capable
[ 27.088] (II) AIGLX: Screen 0 is not DRI capable
[ 27.183] (II) AIGLX: Loaded and initialized /usr/lib/dri/swrast_dri.so
[ 27.183] (II) GLX: Initialized DRISWRAST GL provider for screen 0
[ 27.277] (II) XKB: reuse xkmfile /var/cache/xkb/server-B20D7FC79C7F597315E3E501AEF10E0D866E8E92.xkm
[ 27.405] (II) config/udev: Adding input device lightsensor-level (/dev/event0)
[ 27.406] (**) lightsensor-level: Applying InputClass "default"
[ 27.406] (II) LoadModule: "evdev"
[ 27.408] (II) Loading /usr/lib/xorg/modules/input/evdev_drv.so
[ 27.412] (II) Module evdev: vendor="X.Org Foundation"
[ 27.412] compiled for 1.9.0, module version = 2.4.99
[ 27.412] Module class: X.Org XInput Driver
[ 27.412] ABI class: X.Org XInput driver, version 11.0
[ 27.412] (**) lightsensor-level: always reports core events
[ 27.413] (**) lightsensor-level: Device: "/dev/event0"
[ 27.413] (--) lightsensor-level: Found absolute axes
[ 27.413] (II) lightsensor-level: Configuring as mouse
[ 27.413] (II) XINPUT: Adding extended input device "lightsensor-level" (type: MOUSE)
[ 27.414] (II) lightsensor-level: initialized for absolute axes.
[ 27.416] (II) config/udev: Adding input device h2w headset (/dev/event1)
[ 27.416] (**) h2w headset: Applying InputClass "default"
[ 27.416] (**) h2w headset: always reports core events
[ 27.416] (**) h2w headset: Device: "/dev/event1"
[ 27.417] (--) h2w headset: Found keys
[ 27.417] (II) h2w headset: Configuring as keyboard
[ 27.417] (II) XINPUT: Adding extended input device "h2w headset" (type: KEYBOARD)
[ 27.417] (**) Option "xkb_rules" "evdev"
[ 27.417] (**) Option "xkb_model" "evdev"
[ 27.417] (**) Option "xkb_layout" "us"
[ 27.438] (II) XKB: reuse xkmfile /var/cache/xkb/server-D378AD8F86E560F712A83EE36E4E5E92C595B9BD.xkm
[ 27.445] (II) config/udev: Adding input device synaptics-rmi-touchscreen (/dev/event2)
[ 27.445] (**) synaptics-rmi-touchscreen: Applying InputClass "default"
[ 27.446] (**) synaptics-rmi-touchscreen: always reports core events
[ 27.446] (**) synaptics-rmi-touchscreen: Device: "/dev/event2"
[ 27.446] (--) synaptics-rmi-touchscreen: Found 3 mouse buttons
[ 27.446] (--) synaptics-rmi-touchscreen: Found absolute axes
[ 27.446] (--) synaptics-rmi-touchscreen: Found x and y absolute axes
[ 27.446] (--) synaptics-rmi-touchscreen: Found absolute touchscreen
[ 27.446] (II) synaptics-rmi-touchscreen: Configuring as touchscreen
[ 27.446] (**) synaptics-rmi-touchscreen: YAxisMapping: buttons 4 and 5
[ 27.447] (**) synaptics-rmi-touchscreen: EmulateWheelButton: 4, EmulateWheelInertia: 10, EmulateWheelTimeout: 200
[ 27.447] (II) XINPUT: Adding extended input device "synaptics-rmi-touchscreen" (type: TOUCHSCREEN)
[ 27.447] (II) synaptics-rmi-touchscreen: initialized for absolute axes.
[ 27.449] (II) config/udev: Adding input device mahimahi-keypad (/dev/event3)
[ 27.449] (**) mahimahi-keypad: Applying InputClass "default"
[ 27.450] (**) mahimahi-keypad: always reports core events
[ 27.450] (**) mahimahi-keypad: Device: "/dev/event3"
[ 27.450] (--) mahimahi-keypad: Found keys
[ 27.450] (II) mahimahi-keypad: Configuring as keyboard
[ 27.450] (II) XINPUT: Adding extended input device "mahimahi-keypad" (type: KEYBOARD)
[ 27.450] (**) Option "xkb_rules" "evdev"
[ 27.450] (**) Option "xkb_model" "evdev"
[ 27.450] (**) Option "xkb_layout" "us"
[ 27.453] (II) config/udev: Adding input device mahimahi-nav (/dev/event4)
[ 27.453] (**) mahimahi-nav: Applying InputClass "default"
[ 27.454] (**) mahimahi-nav: always reports core events
[ 27.454] (**) mahimahi-nav: Device: "/dev/event4"
[ 27.454] (--) mahimahi-nav: Found 1 mouse buttons
[ 27.454] (--) mahimahi-nav: Found relative axes
[ 27.454] (--) mahimahi-nav: Found x and y relative axes
[ 27.454] (II) mahimahi-nav: Configuring as mouse
[ 27.454] (**) mahimahi-nav: YAxisMapping: buttons 4 and 5
[ 27.454] (**) mahimahi-nav: EmulateWheelButton: 4, EmulateWheelInertia: 10, EmulateWheelTimeout: 200
[ 27.454] (II) XINPUT: Adding extended input device "mahimahi-nav" (type: MOUSE)
[ 27.455] (**) mahimahi-nav: (accel) keeping acceleration scheme 1
[ 27.455] (**) mahimahi-nav: (accel) acceleration profile 0
[ 27.455] (**) mahimahi-nav: (accel) acceleration factor: 2.000
[ 27.455] (**) mahimahi-nav: (accel) acceleration threshold: 4
[ 27.455] (II) mahimahi-nav: initialized for relative axes.
[ 27.457] (II) config/udev: Adding input device proximity (/dev/event5)
[ 27.458] (**) proximity: Applying InputClass "default"
[ 27.458] (**) proximity: always reports core events
[ 27.458] (**) proximity: Device: "/dev/event5"
[ 27.458] (--) proximity: Found absolute axes
[ 27.458] (II) proximity: Configuring as mouse
[ 27.458] (II) XINPUT: Adding extended input device "proximity" (type: MOUSE)
[ 27.458] (II) proximity: initialized for absolute axes.
[ 27.460] (II) config/udev: Adding input device compass (/dev/event6)
[ 27.461] (**) compass: Applying InputClass "default"
[ 27.461] (**) compass: always reports core events
[ 27.461] (**) compass: Device: "/dev/event6"
[ 27.461] (--) compass: Found absolute axes
[ 27.461] (--) compass: Found x and y absolute axes
[ 27.461] (II) compass: Configuring as mouse
[ 27.462] (II) XINPUT: Adding extended input device "compass" (type: MOUSE)
[ 27.462] (II) compass: initialized for absolute axes.
[ 27.593] (EE) FBDEV(0): FBIOBLANK: Invalid argument
[ 627.616] (EE) FBDEV(0): FBIOBLANK: Invalid argument
[ 627.617] (EE) FBDEV(0): FBIOBLANK: Invalid argument
[ 627.618] (EE) FBDEV(0): FBIOBLANK: Invalid argument
Thank you.
Is there a way to run it on SGS ? ;-)
ReplyDeleteMaybe It can work. SGS also has the Qualcomm Snapdragon. other QSD smartphone might be worked. Key point is if SGS can use the fastboot boot option. If it's not, we should flush MeeGo boot.img to flash memory.
ReplyDeleteSamsung Galaxy S does not use a Qualcomm Snapdragon cpu. SGS uses a hummingbird cpu, which they themselves (along with Intrinsity) made.
ReplyDeleteOh, Sorry :-p If there are kernel source code, and device, I can analyze. I don't have it yet. So I don't know if MeeGo can work on SGS. Does anyone have any information?
ReplyDeleteI wonder if this will work on the hd2 that also uses fastboot...
ReplyDeleteI'll try to port it
Please check the below result of fdisk -l. I used mmcblk0p2 as / partition. :) If you used mmcblk0p1(First partition), you need to specify root=/dev/mmcblk0p1
ReplyDeletewow amazing i will give a try later , its any way to make a flash? so we can change between roms great guide tho
ReplyDeleteZ
year. I'm preparing MeeGo bootable boot.img now. But MeeGo full rootfs is lager than mtdblock spaces. So I try to switch root to microSD from boot.img. Here is the boot sequence.
ReplyDelete1. Power ON
2. Defualt boot. loading boot.img. loading kernel.
3. Loading initrd. mounting the microSD.
4. switch_root /sdcard /sbin/init
5. Boot on MeeGo rootfs from microSD.
And what about Desire? It's the same phone if you look at it in this way. Just kernel bits chagned. It adds all the htc sense stuff and FM Radio. AND it can run N1 kernel without probs if you also make a ROM based on AOSP.
ReplyDeleteHI Mitsutaka ,
ReplyDeleteWould you mind sharing your image. I am having problems setting up my build environment and would like to try this on my xperia x10
Hi !
ReplyDeleteCongratulations for your hack !
Do you think it's possible to port Meego on iPhone ? May be with the help of iDroid ?
Thanks for your help :-)
Hi Dany0, Thank you for information.
ReplyDeleteHi Brad,
ReplyDeleteOkay. I'll upload the image for using easily soon.
Hi Guillaume,
ReplyDeleteI think MeeGo might be worked on iPhone 3G. As you said, If we use iDroid technology, It will work. Also I'll trying to do later.
Thanks for your documentation!
ReplyDeleteI just have problems building the root fs. Could you give me the mic2 command line you use?
Hi sonic,
ReplyDeletemic-image-creator -c meego-handset-armv7l-nexusone-1.1.ks -f raw --run-mode=0 --arch=armv7l
Thanks!
ReplyDeleteBut now there are some errors in your %post script, so the tar file isn't created:
+ sed -e 's/Exec=.*$/\0 -software/' -i /etc/xdg/autostart/meego-im-uiserver.desktop
/bin/sed: can't read /etc/xdg/autostart/meego-im-uiserver.desktop: No such file or directory
+ for prog in '$swprogs'
+ sed -e 's/Exec=.*$/\0 -software/' -i /etc/xdg/autostart/meegotouch-systemui.desktop
+ sed 's!session=\/usr\/bin\/mcompositor!session=\/usr\/bin\/duihome -software \&!' -i /etc/sysconfig/uxlaunch
+ cat
+ chmod +x /sbin/bootchartd-long
+ mkdir -p /home/meego/.mozilla/
+ chown -R meego:meego /home/meego/.mozilla/
+ cat
+ '[' -n meego-handset-armv7l-nexusone-1.1-1.1.20110205.1734 ']'
+ echo 'BUILD: meego-handset-armv7l-nexusone-1.1-1.1.20110205.1734'
++ mount
++ awk '{ print $3 }'
++ sort -r
++ grep /var/tmp/imgcreate-4DZnts/install_root/
/var/tmp/imgcreate-4DZnts/install_root/tmp/ks-script-Y9mcl5: line 9: awk: command not found
grep: write error: Broken pipe
++ pwd
+ outdir=/
+ cd /var/tmp/imgcreate-4DZnts/install_root
+ tar czvf //meego-handset-armv7l-nexusone-1.1-1.1.20110205.1734-rootfs.tar.gz .
/var/tmp/imgcreate-4DZnts/install_root/tmp/ks-script-Y9mcl5: line 11: tar: command not found
thanks a lot for your instructions!
ReplyDeletei do get it up and running, even with adb.
runs horribly slow though, and i get neither a statusbar, nor a touch keyboard... too bad
I tar'ed the files by hand, but booting hang at the Nexus One coloured "X" logo. After enabling the serial console in the kernel (details:
ReplyDeletehttp://sven.killig.de/android/N1/serial
), this was the last output I got:
Welcome to MeeGo
[ OK ]
/etc/rc.d/rc.sysinit: line 372: /proc/sys/kernel/sched_latency_ns: No such file or directory
/etc/rc.d/rc.sysinit: line 373: /proc/sys/kernel/sched_wakeup_granularity_ns: No such file or directory
INIT: Id "x" respawning too fast: disabled for 5 minutes
/etc/rc.d/rc.sysinit: line 394: /sbin/adbd: No such file or directory
INIT: Id "s0" respawning too fast: disabled for 5 minutes
I understand the last one. In the ks:
# open serial line console for embedded system
echo "s0:235:respawn:/sbin/agetty -L 115200 ttyS2 vt100" >> /etc/inittab
I changed ttyS2 to ttyMSM0 and was able to log in. After starting
/usr/bin/xinit /usr/bin/startdui
by hand, the UX came up :-)
serial console config is good information! thanks! so if you prepare the adbd command from android tree or android sdk, you can use adb to install to rootfs.
ReplyDelete
